| Datasheets： |
|
| LTC2262-12： |
|
| DC1369A Demo Manual： |
|
| Product Photos： |
|
| DC1369A-N： |
|
| Software Download： |
|
| PScope： |
|
| Design Resources： |
|
| DC1369A Design Files： |
|
| Standard Package ： |
1 |
| Category： |
Programmers, Development Systems |
| Family： |
Evaluation Boards - Analog to Digital Converters (ADCs) |
| Series： |
PScope™ |
| Number of A/D Converters： |
1 |
| Number of Bits： |
12 |
| Sampling Rate (Per Second)： |
150M |
| Data Interface： |
Parallel |
| Input Range： |
1 ~ 2 Vpp |
| Power (Typ) @ Conditions： |
221mW @ 150MSPS |
| Utilized IC / Part： |
LTC2262-12 |
| Supplied Contents： |
Board |
| Dynamic Catalog： |
LTC22xx-12/14 Demo Board |
| Associated Product： |
DC890B-ND - BOARD USB DATA COLLECTIONLTC2262IUJ-14#TRPBF-ND - IC ADC 14BIT 150MSPS 40-QFNLTC2262IUJ-12#TRPBF-ND - IC ADC 12BIT 150MSPS 40-QFNLTC2262CUJ-14#TRPBF-ND - IC ADC 14BIT 150MSPS 40-QFNLTC2262CUJ-12#TRPBF-ND - IC ADC 12BIT 150MSPS 40-QFNLTC2262IUJ-14#PBF-ND - IC ADC 14BIT 1.8V 150MSPS 40-QFNLTC2262IUJ-12#PBF-ND - IC ADC 12BIT 150MSPS 40-QFNLTC2262CUJ-14#PBF-ND - IC ADC 14BIT 150MSPS 40-QFNLTC2262CUJ-12#PBF-ND - IC ADC 12BIT 150MSPS 40-QFN |
| Other Names： |
DC1369AN |
