型号：	DSPIC30F1010-30I/SP
厂商：	Microchip Technology
标准：
分类：	半导体，集成电路 - IC
描述：	digital signal processors & controllers - dsp, dsc 28-pin 6kb 256bytes- ram 30mips 21i/O
报错收藏赞

Datasheet下载地址

本地下载 >> 厂商下载2 >> 第三方平台下载 >>

DSPIC30F1010-30I/SP的详细信息

Manufacturer：	Microchip
Product Category：	Digital Signal Processors & Controllers - DSP, DSC
RoHS：	Yes
Brand：	Microchip Technology
Core：	dsPIC
Data Bus Width：	16 bit
Program Memory Size：	6 kB
Data RAM Size：	256 B
Maximum Clock Frequency：	15 MHz
Number of Programmable I/Os：	21
Number of Timers：	2
MIPS：	30 MIPs
Operating Supply Voltage：	3 V to 5.5 V
Maximum Operating Temperature：	+ 85 C
Package / Case：	SPDIP-28
Mounting Style：	Through Hole
Core Architecture：	dsPIC
Family：	dsPIC30F
Family / Core：	dsPIC30
Instruction Type：	Fixed/Floating Point
Interface Type：	I2C, SPI, UART
Minimum Operating Temperature：	- 40 C
On-Chip ADC：	Yes
Packaging：	Tube
Processor Series：	dsPIC30F
Product：	DSCs
Program Memory Type：	Flash
Series：	dsPIC30F1010
Factory Pack Quantity：	15
Supply Voltage - Min：	3 V
Type：	dsPIC30
