EMI2121MTTAG的详细信息
| Manufacturer： | ON Semiconductor |
|---|---|
| Product Category： | EMI Filter Beads, Chips & Arrays |
| RoHS： | Yes |
| Product： | EMI Filters, Common Mode |
| Capacitance： | 1.3 pF |
| Maximum DC Current： | 100 mA |
| Maximum DC Resistance： | 8 Ohms |
| Operating Temperature Range： | - 40 C to + 85 C |
| Termination Style： | SMD/SMT |
| Brand： | ON Semiconductor |
| Case Height： | 0.75 mm |
| Case Length： | 2 mm |
| Case Width： | 2.2 mm |
| Cutoff Frequency： | 2 GHz |
| Dimensions： | 2.2 mm W x 2 mm L x 0.75 mm H |
| Frequency Range： | 800 MHz |
| Packaging： | Reel |
| Series： | EMI2121 |
| Factory Pack Quantity： | 3000 |
| Voltage Rating： | 9 V |
EMI2121MTTAG相关文档
- Package Drawing: WDFN8 2.2x2, 0.5P
- Simulation Model: EMI2121MTTAG Spice4 Simulation Model
- Application Note: Consideration of Self-Pollution Reduction for Electronic Systems
- PCN: Final Product / Process Change Notification
- PCN: Addition of FAB 10 (US) as qualified wafer source for Common Mode Filter devices in WDFN package.
- PCN: Final Product / Process Change Notification
