| Datasheets： |
|
| EVAL-AD768x/769x/794xCB： |
|
| AD7942： |
|
| Standard Package ： |
1 |
| Category： |
Programmers, Development Systems |
| Family： |
Evaluation Boards - Analog to Digital Converters (ADCs) |
| Series： |
PulSAR® |
| Number of A/D Converters： |
1 |
| Number of Bits： |
14 |
| Sampling Rate (Per Second)： |
250k |
| Data Interface： |
DSP, MICROWIRE™, QSPI™, Serial, SPI™ |
| Input Range： |
0 ~ VREF |
| Power (Typ) @ Conditions： |
12.5mW @ 250kSPS, 5 V |
| Utilized IC / Part： |
AD7942 |
| Supplied Contents： |
Board |
| Associated Product： |
AD7942BCPZRL-ND - IC ADC 14BIT SAR 250KSPS 10LFCSPAD7942BCPZRL7DKR-ND - IC ADC 14BIT 250KSPS 10-LFCSPAD7942BCPZRL7CT-ND - IC ADC 14BIT 250KSPS 10-LFCSPAD7942BCPZRL7TR-ND - IC ADC 14BIT 250KSPS 10-LFCSPAD7942BRMZ-RL7TR-ND - IC ADC 14BIT SRL 250KSPS 10MSOPAD7942BRMZ-ND - IC ADC 14BIT SRL 250KSPS 10MSOP |
Analog Devices Inc
