Triad Magnetics
FD5-120-B的详细信息
| Datasheets： | |
|---|---|
| Power Transformers, Chassis Mnt： | |
| FD5-120： | |
| Standard Package ： | 40 |
| Category： | Transformers |
| Family： | Power Transformers |
| Series： | Quick Pack |
| Type： | Laminated Core |
| Voltage - Primary： | 115V, 230V |
| Voltage - Secondary (Full Load)： | - |
| Current - Output (Max)： | - |
| Primary Winding(s)： | Dual |
| Secondary Winding(s)： | Single |
| Center Tap： | Yes |
| Power - Max： | 12 VA |
| Mounting Type： | Chassis Mount |
| Termination Style： | Solder, Quick Connect - 0.187" (4.7mm) |
| Size / Dimension： | 71.42mm L x 34.93mm W |
| Height - Seated (Max)： | 41.28mm |
| Voltage - Isolation： | 2500VAC |
