型号: FDBL9401_F085
厂商: Fairchild Semiconductor Fairchild Semiconductor
标准:
分类: 半导体分离式半导体
描述: mosfet TO-leadless, pt8,40v 300a, 0.76mohm
报错 收藏

Datasheet下载地址

厂商下载 >> 厂商下载2 >>

FDBL9401_F085的详细信息

Manufacturer: Fairchild Semiconductor
Product Category: MOSFET
Transistor Polarity: N-Channel
Vds - Drain-Source Breakdown Voltage: 40 V
Vgs - Gate-Source Breakdown Voltage: 20 V
Id - Continuous Drain Current: 300 A
Rds On - Drain-Source Resistance: 0.65 mOhms
Configuration: Single
Vgs th - Gate-Source Threshold Voltage: 4 V
Qg - Gate Charge: 220 nC
Maximum Operating Temperature: + 175 C
Pd - Power Dissipation: 429 W
Mounting Style: SMD/SMT
Package / Case: MO-299A-8
Packaging: Reel
Brand: Fairchild Semiconductor
Channel Mode: Enhancement
Ciss - Input Capacitance: 15900 pF
Fall Time: 52 ns
Minimum Operating Temperature: - 55 C
Rise Time: 82 ns
Typical Turn-Off Delay Time: 106 ns
Unit Weight: 850.052 mg
