IN4001 thru IN4007
PLASTIIC SILIICCON RECTTIFIER
CHENG-YI
ELECTRONIC
VOLTAGE RANGE 50 TO 1000 Volts
CURRENT 1.0 Ampere
DO-41
FEATURE
Low forward voltage
High current capability
Low leakage current
High surge capability
Low cost
MECHANICAL DATA
Case:Molded plastic use UL 94V-0 recognized
Flame retardant epoxy
Terminals:Axial leads, solderable per
MIL-STD-202, method 208
Polarity:Color band denotes cathode
Mounting Position:Any
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Single-phase, half-wave, 60Hz, resistive or inductive load
IN4001 IN4002 IN4003 IN4004 IN4005 IN4006 IN4007 UNITS
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
50
35
50
100
70
200
140
200
400
280
400
600
420
600
800
560
800
1000
700
V
V
V
Maximum DC Blocking Voltage
Maximum Average Forward
100
1000
1.0
A
0
Rectified Current 3/8 Lead Length at T =75 C
A
Maximum Overload Surge 8.3 ms single half sine-wave
50
A
V
0
Maximum Forward Voltage at 1.0A AC and 25 C
1.1
Maximum Full Load Reverse Current, Full Cycle Average
30
0
at 75 C Ambient
0
5.0
50.0
Maximum DC Reverse Current at 25 C
0
at Rated DC Blocking Voltage at 75 C
Typical Junction Capacitance (Note 1)
30
pF
0
Operating and Storage Temperature Range
-65 to +175
C
Notes : 1. Measured at 1.0MHz and applied reverse voltage of 4.0 VDC.
* JEDEC Registered Value.
