INA138NA/3KG4的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Current & Power Monitors & Regulators |
| RoHS： | Yes |
| Accuracy： | +/- 0.5 % |
| Product： | Current Monitors |
| Supply Voltage - Max： | 36 V |
| Supply Voltage - Min： | 2.7 V |
| Operating Temperature Range： | - 40 C to + 125 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | SOT-23-5 |
| Packaging： | Reel |
| Brand： | Texas Instruments |
| Input Voltage Range： | 2.7 V to 36 V |
| Sensing Method： | High Side |
| Series： | INA138 |
| Factory Pack Quantity： | 3000 |
| Supply Current： | 25 uA |
| Unit Weight： | 17.500 mg |
INA138NA/3KG4相关文档
- PCN: Transfer of select devices in the BiPolar process node to SH-BIP-1 Facility
- TINA Reference Design: INA138 TINA-TI Reference Design (Rev. A)
- SPICE Model: INA138 TINA-TI Spice Model
- Reference Design: UCC38C42 30-W Synchronous Buck Converter Reference Design
- SPICE Model: INA138 PSpice Model
- Function Diagram: alt_sbos122c
