| 型号： | KB15CKW01-5C-JC |
| 厂商： |
NKK Switches |
| 标准： |   |
| 分类： | 机电产品 ， 按钮开关 |
| 描述： | switch pushbutton spdt 1A 125v |
| 报错 收藏 赞 | |
KB15CKW01-5C-JC的详细信息
| Datasheets： | |
|---|---|
| KB Series Mini PushButtons ILLUM： | |
| Product Photos： | |
| KB15CKW01-5C-JC： | |
| Product Training Modules： | |
| Switch Basics： | |
| How Illuminated Switches Work： | |
| RoHS Information： | |
| Series, Cert of Compliance： | |
| Catalog Drawings： | |
| KB Series Panel Cutout： | |
| KB Series Round： | |
| PCN Design/Specification： | |
| KB Series Surface Finish 08/Feb/2010： | |
| Standard Package ： | 10 |
| Category： | Switches |
| Family： | Pushbutton Switches |
| Series： | KB |
| Packaging ： | Bulk |
| Type： | Standard, Illuminated |
| Circuit： | SPDT |
| Switch Function： | On-Mom |
| Current Rating： | 1A (AC/DC) |
| Voltage Rating - AC： | 125V |
| Voltage Rating - DC： | 30V |
| Actuator Type： | Round, Button |
| Color - Actuator/Cap： | Clear (Red Filter/Diffuser) |
| Illumination Type, Color： | LED, Red |
| Illumination Voltage (Nominal)： | 1.9 VDC |
| Mounting Type： | Panel Mount, Front |
| Termination Style： | Solder Lug |
| Ingress Protection： | - |
| Features： | - |
| Panel Cutout Dimensions： | Circular - 12.30mm Dia |
| Operating Temperature： | -25°C ~ 50°C |
| Mechanical Life： | 100,000 Cycles |
| Electrical Life： | 50,000 Cycles |
| Dynamic Catalog： | KB Series |
| Associated Product： | 360-2555-ND - LED 1 ELEMNT RED T-1 1/2 BIPIN360-2980-ND - CAP EXTRACTOR FOR MULT SERIES360-1004-ND - PROTECTIVE GUARD KB SER SQ&RND360-1000-ND - WRENCH SOCKET FOR KB SERIES PB |
| Other Names： | 360-1619360-1619-ND360-1984KB15CKW01-5C-JC-ROKB15CKW015CJC |
