型号: | LM258 |
厂商: |
|
分类: | 集成电路 |
描述: | dual operational amplifiers(双通道低功耗运放) |
PDF: | 预览 |
报错 收藏 赞 |
Datasheet下载地址
本地下载 >> |
LM258的详细信息
Feature: | Dual Operational Amplifier |
---|
LM158, LM158A, LM258, LM258A
LM358, LM358A, LM2904, LM2904V
DUAL OPERATIONAL AMPLIFIERS
SLOS068R − JUNE 1976 − REVISED JULY 2010
LM158, LM158A . . . JG PACKAGE
LM258, LM258A . . . D, DGK, OR P PACKAGE
LM358 . . . D, DGK, P, PS, OR PW PACKAGE
LM358A . . . D, DGK, P, OR PW PACKAGE
LM2904 . . . D, DGK, P, PS, OR PW PACKAGE
(TOP VIEW)
D
Wide Supply Range:
− Single Supply . . . 3 V to 32 V
(26 V for LM2904)
− or Dual Supplies . . . + 1.5 V to + 16 V
(+ 13 V for LM2904)
D
D
Low Supply-Current Drain, Independent of
Supply Voltage . . . 0.7 mA Typ
1OUT
1IN−
1IN+
GND
V
CC
1
2
3
4
8
7
6
5
2OUT
2IN−
2IN+
Common-Mode Input Voltage Range
Includes Ground, Allowing Direct Sensing
Near Ground
D
Low Input Bias and Offset Parameters:
− Input Offset Voltage . . . 3 mV Typ
A Versions . . . 2 mV Typ
LM158, LM158A . . . FK PACKAGE
(TOP VIEW)
− Input Offset Current . . . 2 nA Typ
− Input Bias Current . . . 20 nA Typ
A Versions . . . 15 nA Typ
3
2
1
20 19
18
NC
NC
1IN−
NC
1IN+
NC
4
5
6
7
8
D
Differential Input Voltage Range Equal to
Maximum-Rated Supply Voltage . . . 32 V
(26 V for LM2904)
17
16
15
14
2OUT
NC
2IN−
NC
D
D
Open-Loop Differential Voltage
Amplification . . . 100 V/mV Typ
9 10 11 12 13
Internal Frequency Compensation
description/ordering information
NC − No internal connection
These devices consist of two independent,
high-gain frequency-compensated operational
amplifiers designed to operate from a single
supply over a wide range of voltages. Operation from split supplies also is possible if the difference between
the two supplies is 3 V to 32 V (3 V to 26 V for the LM2904), and V is at least 1.5 V more positive than the
CC
input common-mode voltage. The low supply-current drain is independent of the magnitude of the supply
voltage.
Applications include transducer amplifiers, dc amplification blocks, and all the conventional operational
amplifier circuits that now can be implemented more easily in single-supply-voltage systems. For example,
these devices can be operated directly from the standard 5-V supply used in digital systems and easily can
provide the required interface electronics without additional ±5-V supplies.
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
Copyright 2010, Texas Instruments Incorporated
On products compliant to MIL-PRF-38535, all parameters are tested
PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of Texas Instruments
standard warranty. Production processing does not necessarily include
unless otherwise noted. On all other products, production
testing of all parameters.
processing does not necessarily include testing of all parameters.
1
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
