LM2931AD2T-5R4G的详细信息
| Manufacturer： | ON Semiconductor |
|---|---|
| Product Category： | LDO Voltage Regulators |
| RoHS： | Yes |
| Brand： | ON Semiconductor |
| Input Voltage MAX： | 40 V |
| Output Voltage： | 5 V |
| Dropout Voltage - Max： | 200 mV at 10 mA |
| Output Current： | 100 mA |
| Load Regulation： | 14 mV |
| Number of Outputs： | 1 Output |
| Output Type： | Fixed |
| Maximum Operating Temperature： | + 125 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | D2PAK-3 |
| Input Bias Current - Max： | 30 mA |
| Input Voltage MIN： | 14 V |
| Line Regulation： | 4 mV |
| Minimum Operating Temperature： | - 40 C |
| Output Voltage Tolerance： | 3.8 % |
| Packaging： | Reel |
| Product： | LDO Regulators |
| PSRR / Ripple Rejection - Typ： | 90 dB |
| Series： | LM2931 |
| Factory Pack Quantity： | 800 |
| Type： | Linear Voltage Regulator |
| Voltage Regulation Accuracy： | 3.8 % |
LM2931AD2T-5R4G相关文档
- Package Drawing: 3 LEAD D2PAK
- Package Drawing: TO-220, SINGLE GAUGE, 3-LEAD
- Package Drawing: TO-220 5 LEAD
- Package Drawing: DPAK 3 LEAD Single Gauge Surface Mount
- Package Drawing: SOIC-8 Narrow Body
- Package Drawing: 5 LEAD D2PAK
- Package Drawing: TO-220 5 LEAD OFFSET
- Package Drawing: TO-92 (TO-226) 5.33mm Body Height
