LM3886的详细信息
Max. Power to Single-Ended Load : | 100 |
---|---|
Max Speaker Outputs(#) : | 2 |
Power Stage Supply Min(V) : | 9 |
Architecture : | Class AB |
Rating : | Catalog |
Operating Temperature Range(C) : | 0 to 70 |
Analog Supply Max [V] : | 40 |
Min. Supported Single-Ended Load : | 4 |
Control Type : | Hardware |
Closed/Open Loop : | Open |
Estimated Footprint(mm<: | |
sup>: | |
2<: | |
/sup>: | |
) : | [pf]11TO-220[/pf] |
Analog Supply Min [V] : | 9 |
Power Stage Supply Max(V) : | 40 |
Input Type : | Analog |
Package Group : | TO-220 |
Approx. Price (US$) : | 3.10 | 1ku |
SNAS091C –MAY 1999–REVISED MARCH 2013
LM3886 Overture™ Audio Power Amplifier Series
Check for Samples: LM3886
1
FEATURES
DESCRIPTION
The LM3886 is a high-performance audio power
23
•
68W Cont. Avg. Output Power into 4Ω at VCC
±28V
=
=
=
amplifier capable of delivering 68W of continuous
average power to a 4Ω load and 38W into 8Ω with
0.1% THD+N from 20Hz–20kHz.
•
38W Cont. Avg. Output Power into 8Ω at VCC
±28V
The performance of the LM3886, utilizing its Self
Peak Instantaneous Temperature (°Ke) (SPiKe)
protection circuitry, puts it in a class above discrete
and hybrid amplifiers by providing an inherently,
dynamically protected Safe Operating Area (SOA).
SPiKe protection means that these parts are
completely safeguarded at the output against
overvoltage, undervoltage, overloads, including shorts
to the supplies, thermal runaway, and instantaneous
temperature peaks.
•
•
50W Cont. Avg. Output Power into 8Ω at VCC
±35V
135W Instantaneous Peak Output Power
Capability
•
•
•
Signal-to-Noise Ratio ≥ 92dB
An Input Mute Function
Output Protection from a Short to Ground or
to the Supplies via Internal Current Limiting
Circuitry
The LM3886 maintains an excellent signal-to-noise
ratio of greater than 92dB with a typical low noise
floor of 2.0µV. It exhibits extremely low THD+N
values of 0.03% at the rated output into the rated
load over the audio spectrum, and provides excellent
linearity with an IMD (SMPTE) typical rating of
0.004%.
•
•
Output Over-Voltage Protection against
Transients from Inductive Loads
Supply Under-Voltage Protection, not Allowing
Internal Biasing to Occur when |VEE| + |VCC| ≤
12V, thus Eliminating Turn-On and Turn-Off
Transients
•
•
11-Lead TO-220 Package
Wide Supply Range 20V - 94V
APPLICATIONS
•
•
•
•
•
Component stereo
Compact stereo
Self-powered speakers
Surround-sound amplifiers
High-end stereo TVs
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
2
3
Overture is a trademark of dcl_owner.
All other trademarks are the property of their respective owners.
PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
Copyright © 1999–2013, Texas Instruments Incorporated
