LM7805CT的详细信息
Manufacturer: | Fairchild Semiconductor |
---|---|
Product Category: | Linear Voltage Regulators |
RoHS: | Yes |
Output Type: | Fixed |
Output Voltage: | 5 V |
Output Current: | 1 A |
Load Regulation: | 100 mV |
Input Voltage MAX: | 20 V |
Line Regulation: | 100 mV |
Maximum Operating Temperature: | + 125 C |
Mounting Style: | Through Hole |
Package / Case: | TO-220 |
Brand: | Fairchild Semiconductor |
Input Voltage MIN: | 7 V |
Minimum Operating Temperature: | - 40 C |
Number of Outputs: | 1 |
Packaging: | Tube |
Polarity: | Positive |
PSRR / Ripple Rejection - Typ: | 73 dB |
Series: | LM7805 |
Factory Pack Quantity: | 50 |
Unit Weight: | 1.214 g |
August 2013
LM78XX / LM78XXA
3-Terminal 1 A Positive Voltage Regulator
Features
Description
• Output Current up to 1 A
The LM78XX series of three-terminal positive regulators
is available in the TO-220 package and with several fixed
output voltages, making them useful in a wide range of
applications. Each type employs internal current limiting,
thermal shut-down, and safe operating area protection. If
adequate heat sinking is provided, they can deliver over
1 A output current. Although designed primarily as fixed-
voltage regulators, these devices can be used with exter-
nal components for adjustable voltages and currents.
• Output Voltages: 5, 6, 8, 9, 10, 12, 15, 18, 24 V
• Thermal Overload Protection
• Short-Circuit Protection
• Output Transistor Safe Operating Area Protection
(Single Gauge)
TO-220
GND
1. Input
2. GND
1
3. Output
Ordering Information(1)
Output Voltage
Product Number
Operating
Temperature
Package
Packing Method
Tolerance
LM7805CT
LM7806CT
LM7808CT
LM7809CT
LM7810CT
LM7812CT
LM7815CT
LM7818CT
LM7824CT
LM7805ACT
LM7809ACT
LM7810ACT
LM7812ACT
LM7815ACT
±4%
-40°C to +125°C
TO-220
(Single Gauge)
Rail
±2%
0°C to +125°C
Note:
1. Above output voltage tolerance is available at 25°C.
© 2006 Fairchild Semiconductor Corporation
LM78XX / LM78XXA Rev. 1.3.0
www.fairchildsemi.com
1
