LP-12-3800的详细信息
| Datasheets： | |
|---|---|
| LP Series： | |
| Product Photos： | |
| LP-12-3800： | |
| RoHS Information： | |
| RoHS Compliance： | |
| Catalog Drawings： | |
| LP Series Bottom： | |
| LP Series Side： | |
| LP Series Schematic： | |
| Standard Package ： | 20 |
| Category： | Transformers |
| Family： | Power Transformers |
| Series： | LP |
| Type： | Semi-Toroidal |
| Voltage - Primary： | 115V, 230V |
| Voltage - Secondary (Full Load)： | Parallel 6.3V, Series 12.6V |
| Current - Output (Max)： | Parallel 7.6A, Series 3.8A |
| Primary Winding(s)： | Dual |
| Secondary Winding(s)： | Dual |
| Center Tap： | No |
| Power - Max： | 48 VA |
| Mounting Type： | Through Hole |
| Termination Style： | PC Pin |
| Size / Dimension： | 79.20mm L x 63.50mm W |
| Height - Seated (Max)： | 34.90mm |
| Voltage - Isolation： | 1500Vrms |
| Other Names： | 595-1317 |
