LPC2106FBD48/01,15的详细信息
| Manufacturer： | NXP |
|---|---|
| Product Category： | ARM Microcontrollers - MCU |
| RoHS： | Yes |
| Brand： | NXP Semiconductors |
| Core： | ARM7TDMI-S |
| Data Bus Width： | 16 bit/32 bit |
| Maximum Clock Frequency： | 60 MHz |
| Program Memory Size： | 128 kB |
| Data RAM Size： | 64 kB |
| On-Chip ADC： | No |
| Operating Supply Voltage： | 1.8 V, 3.3 V |
| Maximum Operating Temperature： | + 85 C |
| Package / Case： | LQFP |
| Mounting Style： | SMD/SMT |
| Interface Type： | I2C, SPI, UART |
| Length： | 7 mm |
| Minimum Operating Temperature： | - 40 C |
| Number of Programmable I/Os： | 32 |
| Number of Timers： | 2 |
| On-Chip DAC： | No |
| Packaging： | Tray |
| Processor Series： | LPC21 |
| Program Memory Type： | Flash |
| Series： | LPC2000 |
| Factory Pack Quantity： | 250 |
| Tradename： | LPC |
| Part # Aliases： | LPC2106FBD48/01-S |
LPC2106FBD48/01,15相关文档
- Application note: Using the Philips LPC2000 Flash utility with the Keil MCB2100 and IAR LPC210x Kickstart evaluation boards (v.4.0)
- Application note: uC/OS-II Time Management in LPC2000 (v.2.0)
- Other type: TN07002 UUencode (v.1.0)
- User manual: LPC2104/2105/2106 User manual (v.2.0)
- Errata sheet: LPC2106, LPC2106/00 Erratasheet (v.1.9)
- Errata sheet: Errata sheet LPC2106; LPC2106/00 (v.2.0)
- Brochure: Create smarter, more efficient white goods; An industry-leading portfolio of cost-effective, power-saving solutions for major home appliances (v.1.0)
- Brochure: Looking for more 32-bit MCU options? Start here. (v.1.0)
- Other type: LPC2000 I2C slave code example (v.1.0)
- Application note: Migrating to the LPC1700 series (v.1.0)
- Application note: NicheLite for LPC implementation notes (v.2.0)
- Other type: LPC2000 Boot Loader update via ISP (v.1.0)
- Application note: Using IAP for LPC2000 ARM devices (v.2.0)
- Other type: LPC2xxx UART transmitter code example (v.1.0)
- Application note: UART/SPI/I2C code examples (v.1.0)
- Application note: Full-duplex software UART for LPC2000 (v.1.0)
- Software: AN11008 - Flash based non-volatile storage (v.1.0)
- Application note: Interfacing NXP bridge IC with NXP ARM microcontroller (v.1.0)
- Application note: Handling of spurious interrupts in the LPC2000 (v.1.0)
- Other type: AN10835 - LPC2000 series secondary bootloader source code (v.1.0)
- Other type: LPC2xxx SPI master code example (v.1.0)
- Application note: Initialization code/hints for the LPC2000 family (v.1.0)
- Line card: Development Tools for ARM-based MCUs; Select from the Best in Support (v.1.0)
- Application note: LPC2000 secondary bootloader for code update using IAP (v.1.0)
- Application note: UUencoding for UART ISP (v.1.0)
- Other type: LPC2000 Flash ISP Utility v2.2.3 (v.2.2)
- Other type: LPC2000 EINT dual edge interrupts (v.1.0)
- Other type: LPC2000 SPI slave code example (v.1.0)
- Application note: Nesting of interrupts in the LPC2000 (v.1.0)
- Errata sheet: Errata sheet LPC2106/01 (v.1.0)
- Technical note: LPC21xx/22xx, 2104/5/6 revision defect (with software) (v.1.0)
- Application note: Philips LPC210x microcontroller family (v.2.0)
- PCN: Customer Information Notification
