LPC3180FEL320/01,5的详细信息
| Manufacturer： | NXP |
|---|---|
| Product Category： | ARM Microcontrollers - MCU |
| RoHS： | Yes |
| Brand： | NXP Semiconductors |
| Core： | ARM926EJ-S |
| Data Bus Width： | 16 bit/32 bit |
| Maximum Clock Frequency： | 208 MHz |
| Data RAM Size： | 64 kB |
| On-Chip ADC： | Yes |
| Operating Supply Voltage： | 1.2 V |
| Maximum Operating Temperature： | + 85 C |
| Package / Case： | LFBGA-320 |
| Mounting Style： | SMD/SMT |
| Interface Type： | I2C/SPI/UART/USB |
| Length： | 13 mm |
| Minimum Operating Temperature： | - 40 C |
| Number of Programmable I/Os： | 55 |
| Number of Timers： | 2 |
| On-Chip DAC： | No |
| Packaging： | Tray |
| Processor Series： | LPC31 |
| Program Memory Type： | ROMLess |
| Factory Pack Quantity： | 160 |
| Tradename： | LPC |
| Part # Aliases： | LPC3180FEL320/01-S |
LPC3180FEL320/01,5相关文档
- Brochure: Looking for more 32-bit MCU options? Start here. (v.1.0)
- Leaflet: Low-power, ARM9-based microcontroller; 266-MHz, 32-bit microcontroller with ARM9EJ-S™ core LPC3180/01 (v.1.0)
- Application note: PCB layout guidelines for NXP MCUs in BGA packages (v.2.0)
- Application note: Using the LPC32xx VFP (v.1.0)
- Application note: LPC313x NAND flash data and bad block management (v.1.0)
- Brochure: Create smarter, more efficient white goods; An industry-leading portfolio of cost-effective, power-saving solutions for major home appliances (v.1.0)
- User manual: LPC3180 User Manual (v.1.0)
- Application note: UUencoding for UART ISP (v.1.0)
- Line card: Development Tools for ARM-based MCUs; Select from the Best in Support (v.1.0)
