| 型号： | MB6S |
| 厂商： |
 Fairchild Semiconductor |
| 标准： |   |
| 分类： | 半导体 ， 分离式半导体 |
| 描述： | bridge rectifiers 0.5A bridge |
| PDF： | 预览 |
| 报错 收藏 赞 | |
Datasheet下载地址
| 本地下载 >> 厂商下载2 >> 第三方平台下载 >> |
MB6S的详细信息
| Manufacturer： | Fairchild Semiconductor |
|---|---|
| Product Category： | Bridge Rectifiers |
| RoHS： | Yes |
| Product： | Single Phase Bridge |
| Peak Reverse Voltage： | 600 V |
| Maximum RMS Reverse Voltage： | 420 V |
| Forward Continuous Current： | 0.5 A |
| Max Surge Current： | 35 A |
| Forward Voltage Drop： | 1 V |
| Maximum Reverse Leakage Current： | 5 uA |
| Power Dissipation： | 1.4 W |
| Maximum Operating Temperature： | + 150 C |
| Length： | 4.9 mm |
| Width： | 4.2 mm |
| Height： | 2.7 mm |
| Mounting Style： | SMD/SMT |
| Package / Case： | SOIC-4 |
| Packaging： | Reel |
| Brand： | Fairchild Semiconductor |
| Minimum Operating Temperature： | - 55 C |
| Series： | MB6S |
| Factory Pack Quantity： | 3000 |
| Part # Aliases： | MB6S_NL |
| Unit Weight： | 228 mg |
April 2014
MB1S - MB8S
0.5 A Bridge Rectifiers
Description
Features
The MB family of bridge rectifiers is a 0.5 A rectifier fam-
ily that achieves high surge current absorption within a
very small foot print. Within its small 35 mm form factor,
• Low-Leakage
• Surge Overload Rating: 35 A peak
• Ideal for Printed Circuit Board
• UL Certified: UL #E258596
2
the MB family shines in its surge capability. In order to
absorb high surge currents, the design supports a 35 A
2
2
I
rating and a 5.0 A Sec I T rating. Devices in the
FSM
family are also rated to breakdown voltages of up to
1000 V. These features make the MB family ideal for
small power supplies that need a little extra surge capa-
bility.
4
3
For higher I
current ratings, lower profile packaging,
FAV
or lower V values, explore the Fairchild MDB family of
F
bridge rectifiers. For improved V and efficiency values
in the MB package or even higher surge capability, ask
about Fairchild’s pending MBxSV family.
~
~
F
-
+
2
1
SOIC-4
Polarity symbols molded
or mark on body
Ordering Informations
Part Number
MB1S
Marking
MB1S
MB2S
MB4S
MB6S
MB8S
Package
Packing Method
MB2S
MB4S
SOIC-4
Tape and Reel
MB6S
MB8S
© 2007 Fairchild Semiconductor Corporation
MB1S - MB8S Rev. 1.2.3
www.fairchildsemi.com
1
