MC100LVEL12DTG的详细信息
| Manufacturer： | ON Semiconductor |
|---|---|
| Product Category： | Logic Gates |
| RoHS： | Yes |
| Brand： | ON Semiconductor |
| Product： | MUX Gates |
| Logic Family： | 100LV |
| Number of Gates： | 1 |
| Number of Input Lines： | 2 |
| Number of Output Lines： | 4 |
| High Level Output Current： | - 50 mA |
| Low Level Output Current： | 50 mA |
| Propagation Delay Time： | 0.58 ns |
| Supply Voltage - Max： | +/- 3.8 V |
| Supply Voltage - Min： | +/- 3 V |
| Maximum Operating Temperature： | + 85 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | TSSOP-8 |
| Packaging： | Tube |
| Minimum Operating Temperature： | - 40 C |
| Number of Lines In/Out： | 2 / 4 |
| Series： | MC100LVEL12 |
| Factory Pack Quantity： | 100 |
| Part # Aliases： | MC100LVEL12DG |
