Freescale Semiconductor
MC908QB8CDWE的详细信息
| Manufacturer： | Freescale Semiconductor |
|---|---|
| Product Category： | 8-bit Microcontrollers - MCU |
| RoHS： | Yes |
| A/D Bit Size： | 8 bit |
| Core： | HC08 |
| Data Bus Width： | 8 bit |
| Maximum Clock Frequency： | 8 MHz |
| Program Memory Size： | 8 kB |
| Data RAM Size： | 256 B |
| On-Chip ADC： | Yes |
| Operating Supply Voltage： | 3 V to 5 V |
| Maximum Operating Temperature： | + 85 C |
| Package / Case： | SOIC-16 |
| Mounting Style： | SMD/SMT |
| A/D Channels Available： | 8 |
| Brand： | Freescale Semiconductor |
| Data ROM Type： | Flash |
| Interface Type： | SCI, SPI |
| Minimum Operating Temperature： | - 40 C |
| Number of Programmable I/Os： | 14 |
| Number of Timers： | 4 |
| Packaging： | Tube |
| Processor Series： | HC08QB |
| Program Memory Type： | Flash |
| Series： | HC08Q |
| Factory Pack Quantity： | 47 |
| Supply Voltage - Max： | 5.5 V |
| Supply Voltage - Min： | 2.7 V |
| Unit Weight： | 424.200 mg |
MC908QB8CDWE相关文档
- Errata: MSE908QB8_3M62B
- Reference Manuals: CPU08RM
- Package Description: SOIC 16W
- Roadmap: 8BITAUTOROADMAP
- Brochures: BR8BITLOWEND
- Engineering Bulletins: EB349
- Engineering Bulletins: EB615
- Material Composition Declaration (MCD): IPC-1752 Report
- Application Notes Software: AN1221SW
- Application Notes Software: AN1219SW
- Datasheet: MC68HC908QB8
- Errata: MSE908QB8_2M62B
- Application Notes Software: AN2305SW
- Application Notes Software: AN2295SW
- Fact Sheets: CWDEVSTUDFACT.PDF
- Application Notes Software: AN2504SW
- Engineering Bulletins: EB398
- Application Notes Software: AN1222SW
- Application Notes Software: AN1218SW
- Errata: MSE908QB8_3L87X
- Fact Sheets: MC908QB84FS
- PCN: Freescale - PCN 5-20-10
