Freescale Semiconductor
MC9S08JM8CLC的详细信息
| Manufacturer： | Freescale Semiconductor |
|---|---|
| Product Category： | 8-bit Microcontrollers - MCU |
| RoHS： | Yes |
| A/D Bit Size： | 12 bit |
| Core： | S08 |
| Data Bus Width： | 8 bit |
| Maximum Clock Frequency： | 48 MHz |
| Program Memory Size： | 8 kB |
| Data RAM Size： | 1 kB |
| On-Chip ADC： | Yes |
| Operating Supply Voltage： | 2.7 V to 5.5 V |
| Maximum Operating Temperature： | + 85 C |
| Package / Case： | LQFP-32 |
| Mounting Style： | SMD/SMT |
| A/D Channels Available： | 4 |
| Brand： | Freescale Semiconductor |
| Interface Type： | I2C, SPI |
| Minimum Operating Temperature： | - 40 C |
| Number of Programmable I/Os： | 37 |
| Number of Timers： | 2 |
| Packaging： | Tray |
| Processor Series： | MC9S08 |
| Program Memory Type： | Flash |
| Series： | S08JM |
| Factory Pack Quantity： | 1250 |
| Supply Voltage - Max： | 5.5 V |
| Supply Voltage - Min： | 2.7 V |
| Unit Weight： | 188.600 mg |
MC9S08JM8CLC相关文档
- Reference Manuals: DRM104
- BlockDiagramLarge:
- Brochures: BRCONTINUUMCONTR
- Datasheet: MC9S08JM16
- Datasheet: MC9S08JM60
- Reference Manuals: DRM104SW
- Fact Sheets: USBSTKSOLFS
- Quick Reference Guides: DEMO9S08JM60LAB
- Brochures: BRCNTRLCTM
- Application Notes Software: AN3564SW1
- Fact Sheets: MC9S08JM60FS
- BlockDiagramSmall:
- Material Composition Declaration (MCD): IPC-1752 Report
- Package Description: LQFP 32 7*7*1.4P0.8
- Product Briefs: MC9S08JM60PB
- Brochures: BRCTRLCTNUSBSOL
- Application Notes Software: AN3561SW
- Supporting Information: DEMO9S08JM16LAB
- PCN: Product And Process Change Notification
