MC9S08QD4CSC的详细信息
| Manufacturer： | Freescale Semiconductor |
|---|---|
| Product Category： | 8-bit Microcontrollers - MCU |
| RoHS： | Yes |
| A/D Bit Size： | 10 bit |
| Core： | S08 |
| Data Bus Width： | 8 bit |
| Maximum Clock Frequency： | 8 MHz |
| Program Memory Size： | 4 kB |
| Data RAM Size： | 256 B |
| On-Chip ADC： | Yes |
| Operating Supply Voltage： | 2.7 V to 5.5 V |
| Maximum Operating Temperature： | + 85 C |
| Package / Case： | SOIC-8 |
| Mounting Style： | SMD/SMT |
| A/D Channels Available： | 4 |
| Brand： | Freescale Semiconductor |
| Interface Type： | I2C, SCI, SPI |
| Minimum Operating Temperature： | - 40 C |
| Number of Programmable I/Os： | 4 |
| Number of Timers： | 3 |
| Packaging： | Tube |
| Processor Series： | MC9S08 |
| Program Memory Type： | Flash |
| Series： | S08QD |
| Factory Pack Quantity： | 98 |
| Supply Voltage - Max： | 5.5 V |
| Supply Voltage - Min： | 2.7 V |
| Unit Weight： | 74.150 mg |
