Freescale Semiconductor
MC9S08QG8CFFER的详细信息
| Manufacturer： | Freescale Semiconductor |
|---|---|
| Product Category： | 8-bit Microcontrollers - MCU |
| RoHS： | Yes |
| Brand： | Freescale Semiconductor |
| Core： | S08 |
| Data Bus Width： | 8 bit |
| Maximum Clock Frequency： | 20 MHz |
| Program Memory Size： | 8 kB |
| Data RAM Size： | 512 B |
| On-Chip ADC： | Yes |
| Operating Supply Voltage： | 1.8 V to 3.6 V |
| Maximum Operating Temperature： | + 85 C |
| Package / Case： | QFN EP |
| Mounting Style： | SMD/SMT |
| Interface Type： | I2C, SCI, SPI |
| Minimum Operating Temperature： | - 40 C |
| Number of Programmable I/Os： | 12 |
| Number of Timers： | 1 |
| Packaging： | Reel |
| Processor Series： | MC9S08 |
| Program Memory Type： | Flash |
| Series： | S08QG |
| Factory Pack Quantity： | 2500 |
| Supply Voltage - Max： | 3.6 V |
| Supply Voltage - Min： | 1.8 V |
| Unit Weight： | 57.100 mg |
MC9S08QG8CFFER相关文档
- Brochures: 8BITZIGBEEFS.PDF
- Errata: MSE9S08QG8_3M77B
- Fact Sheets: 8BITCIPRODMPFS.PDF
- Reference Manuals: DRM101
- Reference Manuals: HCS08RMV1
- Errata: DE0003
- Engineering Bulletins: EB642
- Users Guides: HCS08QRUGSW
- Application Notes Software: AN2295SW
- Errata: MSE9S08QG8_0M77B
- Package Description: QFN 16 EP 5SQ*1.0P0.8
- Fact Sheets: ZSTARBOARDFS
- Material Composition Declaration (MCD): IPC-1752 Report
- Engineering Bulletins: EB667
- Fact Sheets: MC9S08QG84FS
- Errata: MSE9S08QG8_4M77B
- Brochures: BR8BITLOWEND
- Reference Manuals: DRM086
- Application Notes Software: AN3048SW
- Datasheet: MC9S08QG8
- Brochures: BRMECHATRONICS
- White Papers: QE128SWITCHWP
- Engineering Bulletins: EB618
- Engineering Bulletins: EB666
- Fact Sheets: CWDEVSTUDFACT.PDF
- Errata: MSE9S08QG8_1M77B
- Application Notes Software: AN2949SW1
- Errata: MSEF51QE128_1M12J
- Users Guides: HCS08QRUG
- Engineering Bulletins: EB619
- Brochures: BRDEVTOOLS
- Application Notes Software: AN3031SW.ZIP
- Brochures: 8BITFTPRNTCARD
- PCN: Product And Process Change Notification
- PCN: Product / Process Change Notification
- PCN: Copper Wire Conversion for Microcontroller and Microprocessor Devices
