MC9S12DJ128CFUE的详细信息
| Manufacturer： | Freescale Semiconductor |
|---|---|
| Product Category： | 16-bit Microcontrollers - MCU |
| RoHS： | Yes |
| A/D Bit Size： | 10 bit |
| Core： | HCS12 |
| Data Bus Width： | 16 bit |
| Maximum Clock Frequency： | 25 MHz |
| Program Memory Size： | 128 kB |
| Data RAM Size： | 8 kB |
| On-Chip ADC： | Yes |
| Operating Supply Voltage： | 2.5 V, 5 V |
| Maximum Operating Temperature： | + 85 C |
| Package / Case： | PQFP-80 |
| Mounting Style： | SMD/SMT |
| A/D Channels Available： | 8 |
| Brand： | Freescale Semiconductor |
| Interface Type： | CAN, I2C, SCI, SPI |
| Minimum Operating Temperature： | - 40 C |
| Number of Programmable I/Os： | 59 |
| Number of Timers： | 8 |
| Packaging： | Tray |
| Processor Series： | S12D |
| Program Memory Type： | Flash |
| Series： | S12D |
| Factory Pack Quantity： | 420 |
| Unit Weight： | 1 g |
