MCP1630-E/MS的详细信息
| Manufacturer： | Microchip |
|---|---|
| Product Category： | Switching Controllers |
| RoHS： | Yes |
| Brand： | Microchip Technology |
| Number of Outputs： | 1 |
| Switching Frequency： | 1 MHz |
| Maximum Operating Temperature： | + 125 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | MSOP-8 |
| Packaging： | Tube |
| Fall Time： | 6.2 ns |
| Minimum Operating Temperature： | - 40 C |
| Operating Supply Current： | 2.8 mA |
| Operating Supply Voltage： | 3 V to 5.5 V |
| Rise Time： | 5.9 ns |
| Factory Pack Quantity： | 100 |
MCP1630-E/MS相关文档
- User Guides: MCP1630 NiMH Demo Board User's Guide
- User Guides: 8-Pin SOIC/MSOP/TSSOP/DIP Evaluation Board User's Guide
- User Guides: MCP1630V Bidirectional 4 Cell Li-Ion Charger Ref Design User's Guide
- Brochures: Analog & Interface Guide (Volume 2)
- Product Selection Tools: Analog & Interface Product Selector Guide
- Brochures: LED Lighting Applications Design Guide
- User Guides: MCP1630 Boost Mode LED Driver Demo Board User's Guide
- User Guides: Quick Guide to Microchip Development Tools
- Sell Sheets: MCP1630 High-Speed, Microcontroller-Adaptable, Pulse Width Modulator
- User Guides: MCP1631HV Digitally Controlled Programmable Current Source Reference Design
- User Guides: MCP1630 Li-Ion Multi-Bay Battery Charger Reference Design User's Guide
- User Guides: MCP1630 Low-Cost Li-Ion Battery Charger User's Guide
- User Guides: MCP1630 1A Bias Supply Demo Board User's Guide
- Product Selection Tools: Automotive Recommended Product Selector Guide
MCP1630-E/MS应用笔记
