MG2040MUTAG的详细信息
| Manufacturer： | ON Semiconductor |
|---|---|
| Product Category： | TVS Diode Arrays |
| RoHS： | Yes |
| Channels： | 14 Channels |
| Capacitance： | 0.35 pF |
| Breakdown Voltage： | 5.5 V |
| Clamping Voltage： | 10 V |
| Operating Voltage： | 5 V |
| Peak Surge Current： | 30 A |
| Mounting Style： | SMD/SMT |
| Termination Style： | SMD/SMT |
| Series： | MG2040 |
| Minimum Operating Temperature： | - 55 C |
| Maximum Operating Temperature： | + 125 C |
| Package / Case： | uDFN-18 |
| Brand： | ON Semiconductor |
| Case Height： | 0.45 mm |
| Dimensions： | 1.5 mm W x 5.5 mm L x 0.45 mm H |
| Packaging： | Reel |
| Factory Pack Quantity： | 3000 |
MG2040MUTAG相关文档
- Application Note: Understanding Data Eye Diagram Methodology for Analyzing High Speed Digital Signals
- Application Note: Time Domain Reflection (TDR) Technique for Measuring Signal Path Quality
- Application Note: Interpretation of Datasheet Parameters for ESD Devices
- Application Note: Characterization of ESD Clamping Performance
- Package Drawing: UDFN18, 5.5x1.5, 0.5P
- PCN: MG2040MUTAG Leadframe Change
- PCN: Addition of ASE Shanghai, China as qualified assembly site for Filter & Protection devices in DFN package
- PCN: Final Product / Process Change Notification
