MJ-2505的详细信息
| Datasheets： | |
|---|---|
| MJ-2505： | |
| Product Photos： | |
| MJ-2505： | |
| Catalog Drawings： | |
| MJ-2505 Schematic： | |
| Standard Package ： | 1,000 |
| Category： | Connectors, Interconnects |
| Family： | Barrel - Audio Connectors |
| Series： | - |
| Packaging ： | Bulk |
| Connector Type： | Phone Jack |
| Gender： | Female |
| Signal Lines： | Mono |
| Plug/Mating Plug Diameter： | 2.50mm (0.094", 3/32", Sub Mini, Miniature) - Headphone |
| Number of Positions/Contacts： | 2 Conductors, 3 Contacts |
| Internal Switch(s)： | Single Switch |
| Mounting Type： | Panel Mount |
| Through Hole： | |
| Termination： | Solder Eyelet(s) |
| Shielding： | Unshielded |
| Features： | Mounting Hardware, Thread Lock |
| Color - Contact： | Silver |
| Contact Material： | Brass |
| Contact Material - Plating： | Silver |
| Housing Material： | Plastic |
| Housing Color： | Black |
| Operating Temperature： | -10°C ~ 70°C |
| Voltage - Rated： | 12VDC |
| Current Rating： | 1A |
| Other Names： | CP-2505 |
