MSP430FR5739IRHAR的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | 16-bit Microcontrollers - MCU |
| RoHS： | Yes |
| A/D Bit Size： | 10 bit |
| Core： | MSP430 |
| Data Bus Width： | 16 bit |
| Maximum Clock Frequency： | 24 MHz |
| Program Memory Size： | 15.5 kB |
| Data RAM Size： | 1 kB |
| On-Chip ADC： | Yes |
| Operating Supply Voltage： | 2 V to 3.6 V |
| Maximum Operating Temperature： | + 85 C |
| Package / Case： | VQFN-40 |
| Mounting Style： | SMD/SMT |
| A/D Channels Available： | 12 |
| Brand： | Texas Instruments |
| Data RAM Type： | SRAM |
| Data ROM Size： | 512 B |
| Data ROM Type： | Flash |
| Interface Type： | JTAG |
| Minimum Operating Temperature： | - 40 C |
| Number of Programmable I/Os： | 32 |
| Number of Timers： | 5 x 16 bit |
| On-Chip DAC： | No |
| Packaging： | Reel |
| Processor Series： | 5 Series |
| Program Memory Type： | FRAM |
| Series： | MSP430FR5739 |
| Factory Pack Quantity： | 2500 |
| Tradename： | MSP430 |
MSP430FR5739IRHAR相关文档
- PCN: Qualification of Additional Fab (DMOS6), Assembly/Test (Clark-AT) and Cu Wire Option for select MSP430FR57xx devices in the QFN Package
- Evaluation Kits: MSP-TS430RGZ48C - MSP430 48-pin FRAM Target Board
- Evaluation Kits: Dynamic Near Field Communication (NFC) Type 4B Tag
- Evaluation Kits: MSP430 USB Debugging Interface
- Evaluation Kits: MSP-EXP430FR5739 Experimenter Board
- Evaluation Kits: MSP430FR5xxx 40-Pin Target board only
- Evaluation Kits: Murata SimpleLink Wi-Fi CC3000 FRAM Evaluation Module Kit
- Evaluation Kits: MSP430FR5xxx 40-Pin FET tool and target board combination
- Evaluation Kits: MSP-GANG Production Programmer
- Function Diagram: fbd_slas639i
- Evaluation Kits: Battery-less Near Field Communication (NFC) Keyboard
MSP430FR5739IRHAR应用笔记
- MSP430FR57xx FRAM Quality and Reliability
- Maximizing FRAM Write Speed on the MSP430FR573x
- Migrating from the MSP430F2xx Family to the MSP430FR57xx Family (Rev. A)
- Design Considerations When Using the MSP430 Graphics Library
- MSP430 System-Level ESD Considerations
- Migrating from the USCI Module to the eUSCI Module (Rev. A)
- Wireless Update of the MSP430FR57xx
- C Implementation of Cryptographic Algorithms (Rev. A)
- MSP430 FRAM Quality and Reliability (Rev. A)
- MSP430 FRAM Technology ? How To and Best Practices
