NDD03N50Z-1G的详细信息
| Manufacturer： | ON Semiconductor |
|---|---|
| Product Category： | MOSFET |
| Transistor Polarity： | N-Channel |
| Vds - Drain-Source Breakdown Voltage： | 500 V |
| Vgs - Gate-Source Breakdown Voltage： | 30 V |
| Id - Continuous Drain Current： | 2.6 A |
| Rds On - Drain-Source Resistance： | 3.3 Ohms |
| Configuration： | Single |
| Maximum Operating Temperature： | + 150 C |
| Pd - Power Dissipation： | 58 W |
| Mounting Style： | Through Hole |
| Package / Case： | IPAK-3 |
| Brand： | ON Semiconductor |
| Minimum Operating Temperature： | - 55 C |
| Factory Pack Quantity： | 75 |
NDD03N50Z-1G相关文档
- Simulation Model: NDD03N50Z PSpice Model
- Simulation Model: NDD03N50Z Spice3 Model
- Package Drawing: IPAK (DPAK−3 Insertion Mount)
- Package Drawing: DPAK 4 LEAD Single Gauge Surface Mount
- Simulation Model: NDD03N50Z Saber Model
- Simulation Model: NDD03N50Z Spice2 Model
