ON Semiconductor
NGTB15N120IHRWG的详细信息
| Datasheets： | |
|---|---|
| NGTB15N120IHRWG： | |
| Standard Package ： | 30 |
| Category： | Discrete Semiconductor Products |
| Family： | IGBTs - Single |
| Series： | - |
| Packaging ： | Tube |
| IGBT Type： | Trench and Field Stop |
| Voltage - Collector Emitter Breakdown (Max)： | 1200V |
| Current - Collector (Ic) (Max)： | 30A |
| Current - Collector Pulsed (Icm)： | 60A |
| Vce(on) (Max) @ Vge, Ic： | 2.5V @ 15V, 15A |
| Power - Max： | 333W |
| Switching Energy： | 340µJ (off) |
| Input Type： | Standard |
| Gate Charge： | 160nC |
| Td (on/off) @ 25°C： | -/170ns |
| Test Condition： | 600V, 15A, 10 Ohm, 15V |
| Reverse Recovery Time (trr)： | - |
| Package / Case： | TO-247-3 |
| Mounting Type： | Through Hole |
| Supplier Device Package： | TO-247 |
