NLC453232T-2R2K的详细信息
| Datasheets： | |
|---|---|
| NLC4532： | |
| Product Photos： | |
| NLC4532 Series： | |
| Standard Package ： | 500 |
| Category： | Inductors, Coils, Chokes |
| Family： | Fixed Inductors |
| Series： | NLC |
| Packaging ： | Tape & Reel (TR) |
| Type： | - |
| Material - Core： | - |
| Inductance： | 2.2µH |
| Tolerance： | ±10% |
| Current Rating： | 850mA |
| Current - Saturation： | - |
| Shielding： | Unshielded |
| DC Resistance (DCR)： | 180 mOhm Max |
| Q @ Freq： | 10 @ 7.96MHz |
| Frequency - Self Resonant： | 80MHz |
| Operating Temperature： | -40°C ~ 85°C |
| Frequency - Test： | 7.96MHz |
| Mounting Type： | Surface Mount |
| Package / Case： | 1812 (4532 Metric) |
| Size / Dimension： | 0.177" L x 0.126" W (4.50mm x 3.20mm) |
| Height - Seated (Max)： | 0.134" (3.40mm) |
| Supplier Device Package： | 1812 |
| Other Names： | 445-1160-2 |
