PCA9500PW,112的详细信息
| Manufacturer： | NXP |
|---|---|
| Product Category： | Interface - I/O Expanders |
| RoHS： | Yes |
| Brand： | NXP Semiconductors |
| Logic Family： | PCA9500 |
| Operating Supply Voltage： | 2.5 V to 3.6 V |
| Operating Temperature Range： | - 40 C to + 85 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | TSSOP-16 |
| Packaging： | Tube |
| Output Current： | 25 mA |
| Power Dissipation： | 400 mW |
| Product Type： | I/O Expanders |
| Factory Pack Quantity： | 96 |
| Part # Aliases： | PCA9500PW |
PCA9500PW,112相关文档
- User manual: I2C-bus specification and user manual (v.4.0)
- User manual: PCA9698 demonstration board OM6281 (v.1.0)
- Application note: Level shifting techniques in I2C-bus design (v.1.0)
- User manual: I2C Demonstration Board 2005-1 Quick Start Guide (v.1.0)
- Leaflet: I2C Selection Guide 2H 2011 (v.1.0)
- Application note: PCA9500/PCA9501 provides simple card maintenance and control using I²C-bus (v.2.0)
- Application note: I2C manual (v.1.0)
- Leaflet: Combination GPIO expanders and EEPROMs for smaller boards; NXP 8-bit I2C/SMBus GPIO expanders with 2-K EEPROM PCA9500/01 (v.1.0)
- Other type: Application guide: Set-top boxes (STBs) (v.1.0)
- Brochure: Create smarter, more efficient white goods; An industry-leading portfolio of cost-effective, power-saving solutions for major home appliances (v.1.0)
- Other type: DesignCon 2003 TecForum I 2 C Bus Overview (v.1.0)
- Application note: I2C/SMBus general purpose I/O expanders (v.2.0)
- Application note: A guide to designing for ESD and EMC (v.2.0)
- PCN: Customer Information Notification
