PSMN012-80PS,127的详细信息
| Manufacturer： | NXP |
|---|---|
| Product Category： | MOSFET |
| RoHS： | Yes |
| Brand： | NXP Semiconductors |
| Transistor Polarity： | N-Channel |
| Vds - Drain-Source Breakdown Voltage： | 80 V |
| Id - Continuous Drain Current： | 74 A |
| Rds On - Drain-Source Resistance： | 11 mOhms |
| Pd - Power Dissipation： | 148 W |
| Mounting Style： | Through Hole |
| Package / Case： | TO-220-3 |
| Packaging： | Tube |
| Fall Time： | 6 ns |
| Rise Time： | 16 ns |
| Factory Pack Quantity： | 50 |
| Typical Turn-Off Delay Time： | 33 ns |
PSMN012-80PS,127相关文档
- PCN: Advance Product Change Notification
- Thermal model: PSMN012-80PS Thermal model (v.1.0)
- Leaflet: High performance Trench 6 MOSFETs in a TO220 (v.1.1)
- Selection guide: NXP's Power MOSFET Selection Guide 2012; Smaller, faster, cooler (v.2.1)
- SPICE model: PSMN012-80PS SPICE model (v.1.0)
- Application note: Understanding Power MOSFET Datasheet Parameters (v.1.0)
- PCN: Customer Information Notification
- PCN: Final Product Change Notification
