Delta Electronics
QFR0912UHE-SP01的详细信息
| Datasheets： | |
|---|---|
| QFR0912UHE-SP01 Spec： | |
| QFR 92x92x38MM Series： | |
| Product Photos： | |
| QFR0912UHE-SP01： | |
| Other Related Documents： | |
| Part Number Break-Down and Other Notes： | |
| Product Training Modules： | |
| Fan Options： | |
| RoHS Information： | |
| DC Fans RoHS Cert of Compliance： | |
| Standard Package ： | 48 |
| Category： | Fans, Thermal Management |
| Family： | DC Fans |
| Series： | QFR |
| Voltage - Rated： | 12VDC |
| Size / Dimension： | Square - 92mm L x 92mm H x 38mm W |
| Air Flow： | 131.8 CFM (3.73m³/min) |
| Static Pressure： | 1.466 in H2O (365.2 Pa) |
| Bearing Type： | Ball |
| Fan Type： | Tubeaxial |
| Features： | PWM Control |
| Speed Sensor (Tach)： | |
| Noise： | 62 dB(A) |
| Power (Watts)： | 19.2W |
| RPM： | 8300 RPM |
| Termination： | 4 Wire Leads |
| Ingress Protection： | - |
| Weight： | 0.43 lb (195.04g) |
| Operating Temperature： | 14 ~ 158°F (-10 ~ 70°C) |
| Current Rating： | 1.6A |
| Voltage Range： | 8 ~ 13.2VDC |
| Life Expectancy： | 50000 hrs @ 40°C |
| Material - Frame： | Plastic |
| Material - Blade： | Plastic |
| Dynamic Catalog： | QFR Series |
| Associated Product： | R87F-FL90-ND - FAN FILTER FOR 92X92MM PLASTIC1053-1405-ND - FAN GUARD 92MM WIRE MESH BLACK1053-1404-ND - FAN GUARD 92MM WIRE MESH NATURAL1053-1396-ND - FAN FILTER 92MM 45PPI1053-1385-ND - FAN GUARD PLASTIC 92MM1053-1384-ND - FAN GUARD METAL 92MM BLACK1053-1383-ND - FAN GUARD METAL 92MM381-2397-ND - FAN FILTER ASSEMBLY 92MM381-2346-ND - GRILL GRD FLTR&SPACR F/92MM FANR87F-FG90-ND - GRILL GUARD FOR 92MM FANS259-1627-ND - FAN GUARD 92MM METAL08193-ND - WIRE FORM FAN GUARD 92MM08189-ND - WIRE FORM FAN GUARD 92MM09362-R-ND - PLASTIC FAN GUARD RETAINER 92MM09363-G-ND - PLASTIC FAN GUARD 92MM06362-C-ND - FAN FILTER IRRIDITE CLEAR 92MMQ835-ND - FAN FILTER ANODIZED BLACK 92MMQ331-ND - FILTER GUARD EMI 92MMQ326-ND - FILTER MEDIA 92MM WHITEQ321-ND - FINGER GUARD 92MM BLACKRMS-092-NV-ND - FILTER METAL SCREEN 92X92RFG-092-NV-ND - FINGER GUARD 92X92RFF-092-NV-ND - FILTER FELT 92X92RCPF-092-NV-ND - ASSY GUARD/COVER/FILTER 92X92RCP-092-NV-ND - ASSY GUARD/CVR/SCREEN/FLTR 92X92381-2524-ND - FAN GUARD 92MM PLASTIC381-2523-ND - FAN GUARD 92MM PLASTIC381-2522-ND - FAN GUARD 92MM METALRMF-92/10-ND - FILTER, ME |
