RCJ-2223的详细信息
| Datasheets： | |
|---|---|
| RCJ-22xx： | |
| Product Photos： | |
| RCJ-2223： | |
| RoHS Information： | |
| RCJ-22 Series Cert of Compliance： | |
| Catalog Drawings： | |
| RCJ-22 Series Schematic： | |
| 3D Model： | |
| RCJ-2223： | |
| Standard Package ： | 324 |
| Category： | Connectors, Interconnects |
| Family： | Barrel - Audio Connectors |
| Series： | - |
| Packaging ： | Bulk |
| Connector Type： | Phono (RCA) Jack |
| Gender： | Female |
| Signal Lines： | Mono |
| Plug/Mating Plug Diameter： | 3.20mm ID, 9.00mm OD (RCA) |
| Number of Positions/Contacts： | 2 Sets of 2 Conductors, 3 Contacts |
| Internal Switch(s)： | Does Not Contain Switch |
| Mounting Type： | Through Hole, Right Angle |
| Termination： | Solder |
| Shielding： | Unshielded |
| Features： | Board Lock |
| Color - Contact： | Red, White |
| Contact Material： | Brass |
| Contact Material - Plating： | Nickel |
| Housing Material： | Thermoplastic |
| Housing Color： | Black |
| Operating Temperature： | - |
| Voltage - Rated： | 24VDC |
| Current Rating： | 5A |
| Dynamic Catalog： | CUI |
| Other Names： | 045-0696RCP-1435RCJ2223 |
