Littelfuse Inc
Datasheet下载地址
S4003LS2的详细信息
| Standard Package ： | 250 |
|---|---|
| Category： | Discrete Semiconductor Products |
| Family： | SCRs - Single |
| Series： | - |
| Packaging ： | Bulk |
| Voltage - Off State： | 400V |
| Voltage - Gate Trigger (Vgt) (Max)： | 800mV |
| Current - Gate Trigger (Igt) (Max)： | 200µA |
| Voltage - On State (Vtm) (Max)： | 1.6V |
| Current - On State (It (AV)) (Max)： | 1.9A |
| Current - On State (It (RMS)) (Max)： | 3A |
| Current - Hold (Ih) (Max)： | 6mA |
| Current - Off State (Max)： | 2µA |
| Current - Non Rep. Surge 50, 60Hz (Itsm)： | 25A, 30A |
| SCR Type： | Sensitive Gate |
| Operating Temperature： | -40°C ~ 110°C |
| Mounting Type： | Through Hole |
| Package / Case： | TO-220-3 Isolated Tab |
| Supplier Device Package： | TO-220 Isolated Tab |
