S5LS10106ASPGEQQ1的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | ARM Microcontrollers - MCU |
| RoHS： | Yes |
| A/D Bit Size： | 12 bit |
| Core： | ARM Cortex R4F |
| Data Bus Width： | 16 bit/32 bit |
| Maximum Clock Frequency： | 140 MHz |
| Program Memory Size： | 1024 kB |
| Data RAM Size： | 128 kB |
| On-Chip ADC： | Yes |
| Operating Supply Voltage： | 1.5 V, 3.3 V |
| Maximum Operating Temperature： | + 125 C |
| Package / Case： | LQFP-144 |
| Mounting Style： | SMD/SMT |
| A/D Channels Available： | 20 |
| Brand： | Texas Instruments |
| Data RAM Type： | RAM |
| Interface Type： | SPI, UART |
| Minimum Operating Temperature： | - 40 C |
| On-Chip DAC： | No |
| Program Memory Type： | Flash |
| Series： | TMS570LS10106 |
| Factory Pack Quantity： | 60 |
| Tradename： | Hercules |
S5LS10106ASPGEQQ1相关文档
- Evaluation Kits: XDS100 Low-cost Debug Probe
- Evaluation Kits: XDS560 High Performance Debug Probe
- Evaluation Kits: XDS200 Price/Performance-balanced Debug Probe
- Function Diagram: fbd_spns141f
S5LS10106ASPGEQQ1应用笔记
- 3.3 V I/O Considerations for Hercules Safety MCUs (Rev. A)
- Usage of MPU Subregions on TI Hercules ARM Safety MCUs
- Configuring the Hercules ARM Safety MCU SCI/LIN Module for UART Communication (Rev. A)
- Generating Operating System Tick Using RTI on a Hercules ARM Safety MCU
- Interfacing TPS65381 With Hercules Microcontrollers (Rev. A)
- Configuring a CAN Node on Hercules ARM Safety MCUs
- Verification of Data Integrity Using CRC
- Leveraging the High-End Timer Transfer Unit on Hercules ARM Safety MCUs (Rev. A)
- Important ARM Ltd Application Notes for TI Hercules ARM Safety MCUs
- NHET Getting Started (Rev. B)
- ADC Source Impedance for Hercules ARM Safety MCUs (Rev. B)
