S5LS20216ASPGEQQ1的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | ARM Microcontrollers - MCU |
| RoHS： | Yes |
| Brand： | Texas Instruments |
| Core： | ARM Cortex R4F |
| Data Bus Width： | 16 bit/32 bit |
| Maximum Clock Frequency： | 160 MHz |
| Program Memory Size： | 2 MB |
| Data RAM Size： | 160 kB |
| On-Chip ADC： | Yes |
| Operating Supply Voltage： | 1.5 V, 3.3 V |
| Maximum Operating Temperature： | + 125 C |
| Package / Case： | LQFP-144 |
| Mounting Style： | SMD/SMT |
| Minimum Operating Temperature： | - 40 C |
| Processor Series： | ARM Cortex |
| Program Memory Type： | Flash |
| Series： | TMS570LS20216 |
| Factory Pack Quantity： | 60 |
S5LS20216ASPGEQQ1相关文档
- Evaluation Kits: XDS100 Low-cost Debug Probe
- Evaluation Kits: XDS560 High Performance Debug Probe
- Evaluation Kits: XDS200 Price/Performance-balanced Debug Probe
- Function Diagram: fbd_spns141f
S5LS20216ASPGEQQ1应用笔记
- Compatibility Considerations: TMS570LS20x/10x to TMS570LS31x/21x (Rev. A)
- Interfacing the Embedded 12-Bit ADC in a TMS570LS20x/10x Series Device (Rev. A)
- Programming TMS570LS20x/10x Flash Using Flash API (Rev. A)
- 3.3 V I/O Considerations for Hercules Safety MCUs (Rev. A)
- FlexRay Transfer Unit (FTU) Setup
- Use of Flash Test Pins on TMSx70 F035 Devices (Rev. A)
- Recommended Initializations for TMS570LS20x/10x Microcontrollers
- Configuring the Hercules ARM Safety MCU SCI/LIN Module for UART Communication (Rev. A)
- Verification of Data Integrity Using CRC
- NHET Getting Started (Rev. B)
- ADC Source Impedance for Hercules ARM Safety MCUs (Rev. B)
- Generating Operating System Tick Using RTI on a Hercules ARM Safety MCU
- Configuring a CAN Node on Hercules ARM Safety MCUs
- Basic PBIST Configuration and Influence on Current Consumption (Rev. C)
- Interfacing TPS65381 With Hercules Microcontrollers (Rev. A)
- Usage of MPU Subregions on TI Hercules ARM Safety MCUs
- ECC Handling in TMSx70-Based Microcontrollers
- Important ARM Ltd Application Notes for TI Hercules ARM Safety MCUs
- Leveraging the High-End Timer Transfer Unit on Hercules ARM Safety MCUs (Rev. A)
- Execution Time Measurement for Hercules ARM Safety MCUs (Rev. A)
