Texas Instruments
SN74HC02DE4的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Logic Gates |
| RoHS： | Yes |
| Brand： | Texas Instruments |
| Product： | NOR |
| Logic Family： | 74HC |
| Number of Gates： | 4 |
| Number of Input Lines： | 2 |
| Number of Output Lines： | 1 |
| High Level Output Current： | - 5.2 mA |
| Low Level Output Current： | 5.2 mA |
| Propagation Delay Time： | 90 ns |
| Supply Voltage - Max： | 6 V |
| Supply Voltage - Min： | 2 V |
| Maximum Operating Temperature： | + 85 C |
| Mounting Style： | SMD/SMT |
| Package / Case： | SOIC-14 |
| Packaging： | Tube |
| Minimum Operating Temperature： | - 40 C |
| Number of Lines In/Out： | 2 / 1 |
| Series： | SN74HC02 |
| Factory Pack Quantity： | 50 |
| Unit Weight： | 129.400 mg |
SN74HC02DE4应用笔记
- Selecting the Right Texas Instruments Signal Switch
- Input and Output Characteristics of Digital Integrated Circuits
- CMOS Power Consumption and CPD Calculation (Rev. B)
- Understanding and Interpreting Standard-Logic Data Sheets (Rev. B)
- SN54/74HCT CMOS Logic Family Applications and Restrictions
- Live Insertion
- Designing With Logic (Rev. C)
- TI IBIS File Creation, Validation, and Distribution Processes
- Shelf-Life Evaluation of Lead-Free Component Finishes
- Implications of Slow or Floating CMOS Inputs (Rev. C)
- Using High Speed CMOS and Advanced CMOS in Systems With Multiple Vcc
