Texas Instruments
SN74HC590ANE4的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Counter ICs |
| RoHS： | Yes |
| Brand： | Texas Instruments |
| Counter Type： | Binary |
| Logic Family： | HC |
| Number of Bits： | 8 bit |
| Counting Method： | Synchronous |
| Counting Sequence： | Up |
| Operating Supply Voltage： | 2 V to 6 V |
| Operating Temperature Range： | - 40 C to + 85 C |
| Mounting Style： | Through Hole |
| Package / Case： | PDIP-16 |
| Packaging： | Tube |
| Series： | SN74HC590A |
| Factory Pack Quantity： | 25 |
| Unit Weight： | 1 g |
SN74HC590ANE4相关文档
SN74HC590ANE4应用笔记
- TI IBIS File Creation, Validation, and Distribution Processes
- Designing With Logic (Rev. C)
- HCMOS Design Considerations (Rev. A)
- Shelf-Life Evaluation of Lead-Free Component Finishes
- Implications of Slow or Floating CMOS Inputs (Rev. C)
- Understanding and Interpreting Standard-Logic Data Sheets (Rev. B)
- CMOS Power Consumption and CPD Calculation (Rev. B)
- Selecting the Right Texas Instruments Signal Switch
- Using High Speed CMOS and Advanced CMOS in Systems With Multiple Vcc
- Input and Output Characteristics of Digital Integrated Circuits
- SN54/74HCT CMOS Logic Family Applications and Restrictions
- Live Insertion
