SN74LS75NSR的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | Latches |
| RoHS： | Yes |
| Brand： | Texas Instruments |
| Number of Circuits： | 2 Circuit |
| Logic Type： | Bipolar |
| Logic Family： | LS |
| Polarity： | Inverting/Non-Inverting |
| Number of Output Lines： | 4 Line |
| High Level Output Current： | - 400 uA |
| Low Level Output Current： | 32 mA |
| Propagation Delay Time： | 27 ns at 5 V |
| Supply Voltage - Max： | 5.25 V |
| Supply Voltage - Min： | 4.75 V |
| Maximum Operating Temperature： | + 70 C |
| Minimum Operating Temperature： | 0 C |
| Package / Case： | SOP-16 |
| Packaging： | Reel |
| Mounting Style： | SMD/SMT |
| Number of Input Lines： | 4 Line |
| Series： | SN74LS75 |
| Factory Pack Quantity： | 2000 |
| Supply Current： | 12 mA |
| Unit Weight： | 200.700 mg |
SN74LS75NSR应用笔记
- Designing With Logic (Rev. C)
- Designing with the SN54/74LS123 (Rev. A)
- Shelf-Life Evaluation of Lead-Free Component Finishes
- TI IBIS File Creation, Validation, and Distribution Processes
- Input and Output Characteristics of Digital Integrated Circuits
- Understanding and Interpreting Standard-Logic Data Sheets (Rev. B)
- Live Insertion
