型号：	STM32F030K6T6
厂商：	STMicroelectronics
标准：
分类：	半导体，集成电路 - IC
描述：	arm microcontrollers - mcu entry-level arm cortex-M0 value mcu
PDF：	预览
报错收藏赞

Datasheet下载地址

本地下载 >> 厂商下载 >> 厂商下载2 >>

STM32F030K6T6的详细信息

Manufacturer：	STMicroelectronics
Product Category：	ARM Microcontrollers - MCU
RoHS：	Yes
Core：	ARM Cortex M0
Data Bus Width：	32 bit
Maximum Clock Frequency：	48 MHz
Program Memory Size：	32 kB
Data RAM Size：	4 kB
Operating Supply Voltage：	2.4 V to 3.6 V
Maximum Operating Temperature：	+ 85 C
Package / Case：	LQFP-32
Mounting Style：	SMD/SMT
Brand：	STMicroelectronics
Data RAM Type：	SRAM
Minimum Operating Temperature：	- 40 C
Packaging：	Tray
Processor Series：	ARM Cortex
Program Memory Type：	Flash
Series：	STM32F030K6
Factory Pack Quantity：	250

STM32F030x4 STM32F030x6

STM32F030x8

Value-line ARM-based 32-bit MCU with 16 to 64-KB Flash, timers,

ADC, communication interfaces, 2.4-3.6 V operation

Datasheet target specification

Features

 Core: ARM 32-bit Cortex™-M0 CPU,

frequency up to 48 MHz

 Memories

LQFP64 10x10 mm

LQFP48 7x7 mm

LQFP32 7x7 mm

TSSOP20

– 16 to 64 Kbytes of Flash memory

– 4 to 8 Kbytes of SRAM with HW parity

checking

– One 16-bit basic timer

– Independent and system watchdog timers

– SysTick timer: 24-bit downcounter

 CRC calculation unit

 Reset and power management

 Calendar RTC with alarm and periodic wakeup

– Voltage range: 2.4 V to 3.6 V

from Stop/Standby

– Power-on/Power down reset (POR/PDR)

– Low power modes: Sleep, Stop, Standby

 Communication interfaces

– Up to two I C interfaces: one supporting

 Clock management

Fast Mode Plus (1 Mbit/s) with 20 mA

current sink

– 4 to 32 MHz crystal oscillator

– 32 kHz oscillator for RTC with calibration

– Internal 8 MHz RC with x6 PLL option

– Internal 40 kHz RC oscillator

– Up to two USARTs supporting master

synchronous SPI and modem control; one

with auto baud rate detection

 Up to 55 fast I/Os

– Up to two SPIs (18 Mbit/s) with 4 to 16

programmable bit frame

– All mappable on external interrupt vectors

– Up to 36 I/Os with 5 V tolerant capability

 Serial wire debug (SWD)

 5-channel DMA controller

Table 1. Device summary

 1 x 12-bit, 1.0 µs ADC (up to 16 channels)

Reference

Part number

– Conversion range: 0 to 3.6 V

STM32F030x4 STM32F030F4

– Separate analog supply from 2.4 up to

3.6 V

STM32F030x6 STM32F030C6, STM32F030K6

STM32F030x8 STM32F030C8, STM32F030R8

 Up to 10 timers

– One 16-bit 7-channel advanced-control

timer for 6 channels PWM output, with

deadtime generation and emergency stop

– One 16-bit timer, with up to 4 IC/OC, usable

for IR control decoding

– One 16-bit timer, with 2 IC/OC, 1 OCN,

deadtime generation and emergency stop

– Two 16-bit timers, each with IC/OC and

OCN, deadtime generation, emergency

stop and modulator gate for IR control

– One 16-bit timer with 1 IC/OC

July 2013

DocID024849 Rev 1

1/88

www.st.com
