型号: | STM32F103T8U6 |
厂商: |
|
标准: | ![]() ![]() |
分类: | 半导体 , 集成电路 - IC |
描述: | arm microcontrollers - mcu 32bit cortex M3 FL performance line |
PDF: | 预览 |
报错 收藏 赞 |
STM32F103T8U6的详细信息
Manufacturer: | STMicroelectronics |
---|---|
Product Category: | ARM Microcontrollers - MCU |
RoHS: | Yes |
A/D Bit Size: | 12 bit |
Core: | ARM Cortex M3 |
Data Bus Width: | 32 bit |
Maximum Clock Frequency: | 72 MHz |
Program Memory Size: | 64 kB |
Data RAM Size: | 20 kB |
On-Chip ADC: | Yes |
Operating Supply Voltage: | 2 V to 3.6 V |
Maximum Operating Temperature: | + 85 C |
Package / Case: | UFQFPN-36 |
Mounting Style: | SMD/SMT |
A/D Channels Available: | 10 |
Brand: | STMicroelectronics |
Data RAM Type: | SRAM |
Interface Type: | CAN, I2C, SPI, USART, USB |
Length: | 6 mm |
Minimum Operating Temperature: | - 40 C |
Number of Programmable I/Os: | 26 |
Number of Timers: | 4 |
Packaging: | Tray |
Processor Series: | ARM Cortex |
Program Memory Type: | Flash |
Series: | STM32F103T8 |
Factory Pack Quantity: | 490 |
STM32F103x8
STM32F103xB
Medium-density performance line ARM-based 32-bit MCU with 64
or 128 KB Flash, USB, CAN, 7 timers, 2 ADCs, 9 com. interfaces
Datasheet - production data
Features
ARM 32-bit Cortex™-M3 CPU Core
– 72 MHz maximum frequency,
UFQFPN48 7 × 7 mm
VFQFPN36 6 × 6 mm
1.25 DMIPS/MHz (Dhrystone 2.1)
performance at 0 wait state memory
access
– Single-cycle multiplication and hardware
division
BGA100 10 × 10 mm
UFBGA100 7 x 7 mm
BGA64 5 × 5 mm
LQFP100 14 × 14 mm
LQFP64 10 × 10 mm
LQFP48 7 × 7 mm
Memories
Debug mode
– 64 or 128 Kbytes of Flash memory
– 20 Kbytes of SRAM
– Serial wire debug (SWD) & JTAG
interfaces
Clock, reset and supply management
7 timers
– 2.0 to 3.6 V application supply and I/Os
– Three 16-bit timers, each with up to 4
IC/OC/PWM or pulse counter and
– POR, PDR, and programmable voltage
detector (PVD)
quadrature (incremental) encoder input
– 4-to-16 MHz crystal oscillator
– Internal 8 MHz factory-trimmed RC
– Internal 40 kHz RC
– 16-bit, motor control PWM timer with dead-
time generation and emergency stop
– 2 watchdog timers (Independent and
Window)
– PLL for CPU clock
– 32 kHz oscillator for RTC with calibration
– SysTick timer 24-bit downcounter
Low power
Up to 9 communication interfaces
– Sleep, Stop and Standby modes
2
– Up to 2 x I C interfaces (SMBus/PMBus)
– V
supply for RTC and backup registers
BAT
– Up to 3 USARTs (ISO 7816 interface, LIN,
IrDA capability, modem control)
2 x 12-bit, 1 µs A/D converters (up to 16
channels)
– Up to 2 SPIs (18 Mbit/s)
– CAN interface (2.0B Active)
– USB 2.0 full-speed interface
– Conversion range: 0 to 3.6 V
– Dual-sample and hold capability
– Temperature sensor
CRC calculation unit, 96-bit unique ID
DMA
®
Packages are ECOPACK
– 7-channel DMA controller
– Peripherals supported: timers, ADC, SPIs,
Table 1. Device summary
2
I Cs and USARTs
Reference
Part number
Up to 80 fast I/O ports
STM32F103C8, STM32F103R8
STM32F103V8, STM32F103T8
STM32F103x8
– 26/37/51/80 I/Os, all mappable on 16
external interrupt vectors and almost all
5 V-tolerant
STM32F103RB STM32F103VB,
STM32F103CB, STM32F103TB
STM32F103xB
August 2013
DocID13587 Rev 16
This is information on a product in full production.
