型号：	STM32F429IGT6
厂商：	STMicroelectronics
标准：
分类：	半导体，集成电路 - IC
描述：	arm microcontrollers - mcu dsp fpu arm cortexm4 1mb flash 180mhz
PDF：	预览
报错收藏赞

Datasheet下载地址

本地下载 >> 厂商下载 >> 厂商下载2 >>

STM32F429IGT6的详细信息

Manufacturer：	STMicroelectronics
Product Category：	ARM Microcontrollers - MCU
RoHS：	Yes
Core：	ARM Cortex M4
Data Bus Width：	32 bit
Maximum Clock Frequency：	180 MHz
Program Memory Size：	1024 kB
Data RAM Size：	256 kB
On-Chip ADC：	Yes
Operating Supply Voltage：	1.8 V to 3.6 V
Maximum Operating Temperature：	+ 85 C
Package / Case：	LQFP-176
Mounting Style：	SMD/SMT
A/D Bit Size：	12 bit
A/D Channels Available：	24
Brand：	STMicroelectronics
Data RAM Type：	SRAM
Interface Type：	CAN, I2C, SAI, SDIO, SPI, UART, USART, USB
Minimum Operating Temperature：	- 40 C
Number of Programmable I/Os：	140
Number of Timers：	14
On-Chip DAC：	Yes
Packaging：	Tray
Processor Series：	ARM Cortex
Program Memory Type：	Flash
Series：	STM32F429IG
Factory Pack Quantity：	40

STM32F429xx

ARM Cortex-M4 32b MCU+FPU, 225DMIPS, up to 2MB Flash/256+4KB RAM, USB

OTG HS/FS, Ethernet, 17 TIMs, 3 ADCs, 20 comm. interfaces, camera & LCD-TFT

Data brief

Features

&"'!

• Core: ARM 32-bit Cortex™-M4 CPU with FPU,

LQFP100 (14 × 14 mm)

Adaptive real-time accelerator (ART

LQFP144 (20 × 20 mm)

LQFP176 (24 × 24 mm)

LQFP208 (28 x 28 mm)

UFBGA176 (10 × 10 mm)

TFBGA216 (13 x 13 mm)

Accelerator™) allowing 0-wait state execution

from Flash memory, frequency up to 180 MHz,

MPU, 225 DMIPS/1.25 DMIPS/MHz

WLCSP143

– Cortex-M4 Embedded Trace Macrocell™

• Up to 168 I/O ports with interrupt capability

– Up to 164 fast I/Os up to 84 MHz

– Up to 166 5 V-tolerant I/Os

(Dhrystone 2.1), and DSP instructions

• Memories

– Up to 2 MB of Flash memory organized into

two banks allowing read-while-write

– Up to 256+4 KB of SRAM including 64-KB

of CCM (core coupled memory) data RAM

• Up to 21 communication interfaces

– Up to 3 × I C interfaces (SMBus/PMBus)

– Up to 4 USARTs/4 UARTs (11.25 Mbit/s,

ISO7816 interface, LIN, IrDA, modem

control)

– Flexible external memory controller with up

to 32-bit data bus: SRAM,PSRAM,SDRAM,

Compact Flash/NOR/NAND memories

– Up to 6 SPIs (42 Mbits/s), 2 with muxed

• LCD parallel interface, 8080/6800 modes

• LCD-TFT controller up to VGA resolution with

dedicated Chrom-ART Accelerator™ for

full-duplex I S for audio class accuracy via

internal audio PLL or external clock

– 1 x SAI (serial audio interface)

– 2 × CAN (2.0B Active) and SDIO interface

• Advanced connectivity

enhanced graphic content creation (DMA2D)

• Clock, reset and supply management

– 1.8 V to 3.6 V application supply and I/Os

– POR, PDR, PVD and BOR

– USB 2.0 full-speed device/host/OTG

controller with on-chip PHY

– USB 2.0 high-speed/full-speed

device/host/OTG controller with dedicated

DMA, on-chip full-speed PHY and ULPI

– 10/100 Ethernet MAC with dedicated DMA:

supports IEEE 1588v2 hardware, MII/RMII

– 4-to-26 MHz crystal oscillator

– Internal 16 MHz factory-trimmed RC (1%

accuracy)

– 32 kHz oscillator for RTC with calibration

– Internal 32 kHz RC with calibration

•

Low power

• 8- to 14-bit parallel camera interface up to

54 MBs/s

– Sleep, Stop and Standby modes

– V

supply for RTC, 20×32 bit backup

• True random number generator

• CRC calculation unit

• 96-bit unique ID

BAT

registers + optional 4 KB backup SRAM

• 3×12-bit, 2.4 MSPS ADC: up to 24 channels

and 7.2 MSPS in triple interleaved mode

• RTC: subsecond accuracy, hardware calendar

• 2×12-bit D/A converters

Table 1. Device summary

• General-purpose DMA: 16-stream DMA

Reference

Part number

controller with FIFOs and burst support

STM32F429VG, STM32F429ZG, STM32F429IG,

STM32F429VI, STM32F429ZI, STM32F429II,

STM32F429BG, STM32F429BI, STM32F429NI,

STM32F429NG

• Up to 17 timers: up to twelve 16-bit and two 32-

bit timers up to 180 MHz, each with up to 4

IC/OC/PWM or pulse counter and quadrature

(incremental) encoder input

STM32F429xx

• Debug mode

– SWD & JTAG interfaces

May 2013

Doc ID 023140 Rev 2

1/102

For further information contact your local STMicroelectronics sales office.

www.st.com
