型号：	TB6612FNG(O,C,8,EL
厂商：	Toshiba
标准：
分类：	半导体，集成电路 - IC
描述：	motor / motion / ignition controllers & drivers 15v bridge drvr for brushed DC motors
PDF：	预览
报错收藏赞

Datasheet下载地址

本地下载 >> 厂商下载 >>

TB6612FNG(O,C,8,EL的详细信息

Manufacturer：	Toshiba
Product Category：	Motor / Motion / Ignition Controllers & Drivers
RoHS：	Yes
Packaging：	Reel
Brand：	Toshiba
Factory Pack Quantity：	2000

TB6612FNG

Toshiba Bi-CD Integrated Circuit Silicon Monolithic

TB6612FNG

Driver IC for Dual DC motor

TB6612FNG is a driver IC for DC motor with output transistor in

LD MOS structure with low ON-resistor. Two input signals, IN1

and IN2, can choose one of four modes such as CW, CCW, short

brake, and stop mode.

Features

•

Power supply voltage: VM = 15 V(Max)

Output current: I = 1.2 A(ave)/3.2 A (peak)

Weight: 0.14 g (typ.)

OUT

Output low ON resistor: 0.5Ω (upper+lower Typ. @ VM ≥ 5 V)

Standby (Power save) system

CW/CCW/short brake/stop function modes

Built-in thermal shutdown circuit and low voltage detecting circuit

Small faced package(SSOP24: 0.65 mm Lead pitch)

This product has a MOS structure and is sensitive to electrostatic discharge. When handling this product,

ensure that the environment is protected against electrostatic discharge by using an earth strap, a conductive

mat and an ionizer. Ensure also that the ambient temperature and relative humidity are maintained at

reasonable levels.

2012-11-01
