Toshiba Semiconductor and Storage
Datasheet下载地址
| 厂商下载 >> |
TC4S81FT5LFT的详细信息
| Datasheets： | |
|---|---|
| TC4S81F： | |
| Product Photos： | |
| SC-74A, SOT-753： | |
| Standard Package ： | 3,000 |
| Category： | Integrated Circuits (ICs) |
| Family： | Logic - Gates and Inverters |
| Series： | TC4S |
| Packaging ： | Tape & Reel (TR) |
| Logic Type： | AND Gate |
| Number of Circuits： | 1 |
| Number of Inputs： | 2 |
| Features： | - |
| Voltage - Supply： | 3 V ~ 18 V |
| Current - Quiescent (Max)： | 1µA |
| Current - Output High, Low： | 3.4mA, 3.4mA |
| Logic Level - Low： | 1.5 V ~ 4 V |
| Logic Level - High： | 3.5 V ~ 11 V |
| Max Propagation Delay @ V, Max CL： | 80ns @ 15V, 50pF |
| Operating Temperature： | -40°C ~ 85°C |
| Mounting Type： | Surface Mount |
| Supplier Device Package： | SMV |
| Package / Case： | SC-74A, SOT-753 |
| Dynamic Catalog： | 4S |
| Other Names： | TC4S81F(T5L,F,T)TC4S81F(TE85L,F)TC4S81F(TE85LF)TRTC4S81F(TE85LF)TR-NDTC4S81FT5LFT-NDTC4S81FT5LFTTR |
