TC74HC574AP(F)的详细信息
| Datasheets： | |
|---|---|
| TC74HC564,574 AF, AP ： | |
| Product Photos： | |
| 20-DIP： | |
| 20-DIP： | |
| Standard Package ： | 20 |
| Category： | Integrated Circuits (ICs) |
| Family： | Logic - Flip Flops |
| Series： | TC74HC |
| Packaging ： | Tube |
| Function： | Standard |
| Type： | D-Type |
| Output Type： | Tri-State, Non-Inverted |
| Number of Elements： | 1 |
| Number of Bits per Element： | 8 |
| Frequency - Clock： | 59MHz |
| Max Propagation Delay @ V, Max CL： | 33ns @ 6V, 150pF |
| Trigger Type： | Positive Edge |
| Current - Output High, Low： | 7.8mA, 7.8mA |
| Voltage - Supply： | 2 V ~ 6 V |
| Current - Quiescent： | 4µA |
| Input Capacitance： | 5pF |
| Operating Temperature： | -40°C ~ 85°C (TA) |
| Mounting Type： | Through Hole |
| Package / Case： | 20-DIP (0.300", 7.62mm) |
| Dynamic Catalog： | 74HC |
| Other Names： | TC74HC574APF |
