Fairchild Semiconductor
TIP122的详细信息
| Manufacturer： | Fairchild Semiconductor |
|---|---|
| Product Category： | Transistors Darlington |
| RoHS： | Yes |
| Configuration： | Single |
| Transistor Polarity： | NPN |
| Collector- Emitter Voltage VCEO Max： | 100 V |
| Emitter- Base Voltage VEBO： | 5 V |
| Collector- Base Voltage VCBO： | 100 V |
| Maximum DC Collector Current： | 5 A |
| Maximum Collector Cut-off Current： | 200 uA |
| Maximum Operating Temperature： | + 150 C |
| Mounting Style： | Through Hole |
| Package / Case： | TO-220AB |
| Packaging： | Bulk |
| Brand： | Fairchild Semiconductor |
| DC Collector/Base Gain hfe Min： | 1000 at 0.5 A at 3 V, 1000 at 3 A at 3 V |
| Minimum Operating Temperature： | - 65 C |
| Series： | TIP122 |
| Factory Pack Quantity： | 200 |
| Part # Aliases： | TIP122_NL |
| Unit Weight： | 1.214 g |
October 2008
TIP120/TIP121/TIP122
NPN Epitaxial Darlington Transistor
•
•
Medium Power Linear Switching Applications
Complementary to TIP125/126/127
Equivalent Circuit
C
B
TO-220
1
R1
R2
1.Base 2.Collector 3.Emitter
E
R1 @ 8kW
R2 @ 0.12kW
Absolute Maximum Ratings*
T
= 25°C unless otherwise noted
a
Symbol
Parameter
Ratings
Units
VCBO
Collector-Base Voltage : TIP120
60
80
100
V
V
V
: TIP121
: TIP122
VCEO
Collector-Emitter Voltage : TIP120
60
80
100
V
V
V
: TIP121
: TIP122
VEBO
IC
ICP
IB
Emitter-Base Voltage
5
V
A
Collector Current (DC)
Collector Current (Pulse)
Base Current (DC)
5
8
120
A
mA
W
W
°C
°C
PC
Collector Dissipation (Ta=25°C)
Collector Dissipation (TC=25°C)
Junction Temperature
2
65
TJ
150
TSTG
Storage Temperature
- 65 ~ 150
* These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.
© 2007 Fairchild Semiconductor Corporation
TIP120/TIP121/TIP122 Rev. 1.0.0
www.fairchildsemi.com
1
