TLP705A(F)的详细信息
| Datasheets： | |
|---|---|
| Photocouplers/Relays Catalog： | |
| TLP705A： | |
| Product Photos： | |
| TLP718(F)： | |
| Product Training Modules： | |
| IC Photocoupler Overview： | |
| Standard Package ： | 100 |
| Category： | Isolators |
| Family： | Isolators - Gate Drivers |
| Series： | - |
| Packaging ： | Tube |
| Technology： | Optical Coupling |
| Number of Channels： | 1 |
| Voltage - Isolation： | 5000Vrms |
| Common Mode Transient Immunity (Min)： | 20kV/µs |
| Propagation Delay tpLH / tpHL (Max)： | 170ns, 170ns |
| Pulse Width Distortion (Max)： | 50ns |
| Rise / Fall Time (Typ)： | 35ns, 15ns |
| Current - Output High, Low： | 400mA, 400mA |
| Current - Peak Output： | 600mA |
| Voltage - Forward (Vf) (Typ)： | 1.57V |
| Current - DC Forward (If) (Max)： | 25mA |
| Voltage - Supply： | 10 V ~ 30 V |
| Operating Temperature： | -40°C ~ 100°C |
| Mounting Type： | Surface Mount |
| Package / Case： | 6-SOIC (0.268", 6.80mm Width) |
| Supplier Device Package： | 6-SDIP Gull Wing |
| Approvals： | cUR, UR |
| Dynamic Catalog： | Gate Drivers |
| Other Names： | TLP705A (F)TLP705AF |
