| 型号： | TMS320F28026FPTT |
| 厂商： |
 Texas Instruments |
| 标准： |  |
| 分类： | 半导体 ， 集成电路 - IC |
| 描述： | 32-bit microcontrollers - mcu piccolo microcntrllr |
| 报错 收藏 赞 | |
Datasheet下载地址
| 本地下载 >> 厂商下载2 >> 第三方平台下载 >> |
TMS320F28026FPTT的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | 32-bit Microcontrollers - MCU |
| Core： | C28x |
| Data Bus Width： | 32 bit |
| Maximum Clock Frequency： | 50 MHz |
| Program Memory Size： | 32 kB |
| Data RAM Size： | 6 kB |
| On-Chip ADC： | Yes |
| Operating Supply Voltage： | 3.3 V |
| Maximum Operating Temperature： | + 105 C |
| Package / Case： | LQFP-48 |
| Mounting Style： | SMD/SMT |
| A/D Bit Size： | 12 bit |
| A/D Channels Available： | 8 |
| Brand： | Texas Instruments |
| Data RAM Type： | RAM |
| Data ROM Size： | 1 kB |
| Data ROM Type： | ROM |
| Interface Type： | I2C, SCI, SPI, UART |
| Minimum Operating Temperature： | - 40 C |
| Number of Programmable I/Os： | 22 |
| Number of Timers： | 3 |
| On-Chip DAC： | Yes |
| Program Memory Type： | Flash |
| Series： | TMS320F28026 |
| Factory Pack Quantity： | 250 |
| Tradename： | Piccolo |
TMS320F28026FPTT相关文档
- PCN: Aizu Facility as an additional FAB source for select devices in the F05 Process
- Evaluation Kits: XDS100 Low-cost Debug Probe
- Evaluation Kits: controlCARD with Piccolo TMS320F28027FPTT, InstaSPIN?-FOC enabled
- Evaluation Kits: High Voltage Motor Control Kit with InstaSPIN-FOC and InstaSPIN-MOTION enabled Piccolo MCU
- Evaluation Kits: High Voltage Motor Control and PFC Developer's Kit
- Evaluation Kits: GUI Composer Runtime Installation and Webapp for Universal InstaSPIN-FOC GUI
- Reference Design: TMS320C28x DSP CPU and Instruction Set Reference Guide (Rev. E)
- Evaluation Kits: controlCARD with Piccolo TMS320F28069MPZT, InstaSPIN-FOC and InstaSPIN-MOTION enabled
- Evaluation Kits: InstaSPIN?-FOC enabled C2000 Piccolo LaunchPad
- Evaluation Kits: Motor Drive BoosterPack featuring DRV8301 and NexFET? MOSFETs
- Evaluation Kits: XDS560 High Performance Debug Probe
- Evaluation Kits: C2000 Gang Programmer
- Function Diagram: fbd_sprs523j
- Evaluation Kits: C2000 Resolver to Digital Conversion Kit
- Evaluation Kits: Solar Micro Inverter Development Kit
- Evaluation Kits: GUI Composer Runtime Installation and Webapp for MotorWare Universal GUI
TMS320F28026FPTT应用笔记
- TPS75005 Quick-Start Guide with C2000? Controllers
- Programming External Nonvolatile Memory Using SDFlash for TMS320C28x Devices
- Piccolo TMS320F2802x/2803x Migration to TMS320F2806x
- InstaSPIN(tm) BLDC Lab
- Common Object File Format (COFF)
- Digitally Controlled HV Solar MPPT DC-DC Converter Using C2000 Piccolo MCU
- TMS320F280x to TMS320F2802x/TMS320F2803x Migration (Rev. B)
- Multi-DC/DC Conversion & Color LED Control Integrated on a C2000 Microcontroller
- PSFB Control Using C2000 Microcontrollers
- High-Voltage Half-Bridge LLC Resonant DC/DC Conv SW w/ Synch Rectification Kit
- EEPROM Emulation With the TMS320F28xxx DSCs
