| 型号： | TMS320F28030RSHT |
| 厂商： |
 Texas Instruments |
| 标准： |   |
| 分类： | 半导体 ， 集成电路 - IC |
| 描述： | 32-bit microcontrollers - mcu piccolo micro controller |
| 报错 收藏 赞 | |
TMS320F28030RSHT的详细信息
| Manufacturer： | Texas Instruments |
|---|---|
| Product Category： | 32-bit Microcontrollers - MCU |
| RoHS： | Yes |
| Brand： | Texas Instruments |
| Core： | C28x |
| Data Bus Width： | 32 bit |
| Maximum Clock Frequency： | 60 MHz |
| Program Memory Size： | 16 kB |
| Data RAM Size： | 6 kB |
| On-Chip ADC： | Yes |
| Operating Supply Voltage： | 1.8 V, 3.3 V |
| Maximum Operating Temperature： | + 125 C |
| Package / Case： | VQFN-56 |
| Mounting Style： | SMD/SMT |
| Interface Type： | I2C, SPI, UART |
| Number of Programmable I/Os： | 26 |
| Number of Timers： | 3 |
| Processor Series： | Piccolo |
| Program Memory Type： | Flash |
| Series： | TMS320F28030 |
| Factory Pack Quantity： | 160 |
| Tradename： | Piccolo |
TMS320F28030RSHT相关文档
- Evaluation Kits: C2000 Power Line Communications Add-on Kit
- Evaluation Kits: C2000 Digital Power Training Kit
- Evaluation Kits: C2000 Piccolo MCU AC LED Lighting & Communications Kit
- Evaluation Kits: Piccolo TMS320F28035 Isolated controlCARD
- Evaluation Kits: XDS560 High Performance Debug Probe
- Evaluation Kits: C2000 Gang Programmer
- Evaluation Kits: DRV8412 Integrated Motor Driver for Brushed and Stepper Motors with Piccolo F28035 controlCARD
- Evaluation Kits: Three Phase BLDC Motor Kit with DRV8312 and Piccolo MCU
- Evaluation Kits: controlCARD with Piccolo TMS320F28027FPTT, InstaSPIN?-FOC enabled
- Reference Design: TMS320C28x DSP CPU and Instruction Set Reference Guide (Rev. E)
- Evaluation Kits: XDS100 Low-cost Debug Probe
- Evaluation Kits: C2000 2 Phase Interleaved Power Factor Correction Kit with integrated power metering
- Function Diagram: fbd_sprs584j
- Evaluation Kits: C2000 Resolver to Digital Conversion Kit
- Evaluation Kits: Solar Micro Inverter Development Kit
TMS320F28030RSHT应用笔记
- Sensorless Trapezoidal Control of BLDC Motors
- PSFB Control Using C2000 Microcontrollers
- TMS320F280x to TMS320F2802x/TMS320F2803x Migration (Rev. B)
- Sensored Field Oriented Control of 3-Phase Induction Motors
- Software Implementation of PMBus over I2C for TMS320F2803x
- Sensorless Field Oriented Control of 3-Phase Induction Motors Using CLA
- Sensored Field Oriented Control of 3-Phase Permanent Magnet Synchronous Motors
- Scalar (V/f) Control of 3-Phase Induction Motors
- Digital Peak Current Mode Control With Slope Compensation Using the TMS320F2803x (Rev. A)
- EEPROM Emulation With the TMS320F28xxx DSCs
- Sensorless Field Oriented Control:3-Phase Perm.Magnet Synch. Motors With CLA
- Piccolo MCU CAN Module Operation Using the On-Chip Zero-Pin Oscillator (Rev. A)
- Sensorless Field Oriented Control of 3-Phase Induction Motors
- Sensorless Field Oriented Control of 3-Phase Permanent Magnet Synchronous Motors
- TPS75005 Quick-Start Guide with C2000? Controllers
- LED Lighting & DC/DC Conversion Control Integrated on One C2000 Microcontroller
- InstaSPIN(tm) BLDC Lab
- Digital Control of Two Phase Interleaved PFC and Motor Drive Using MCU With CLA
- Programming External Nonvolatile Memory Using SDFlash for TMS320C28x Devices
- Piccolo TMS320F2802x/2803x Migration to TMS320F2806x
- Digitally Controlled HV Solar MPPT DC-DC Converter Using C2000 Piccolo MCU
- Trapezoidal Control of BLDC Motors Using Hall Effect Sensors
- Sensorless Field Oriented Control of Multiple Permanent Magnet Motors
